Manual for C330

Before using the camera: Read instructions carefully and learn correct handling methods to maximize the camera's potential for many years.

Congratulations on your choice: The Mamiya C330S is an exceptionally high-grade camera, building on the popular Mamiya C series with further improvements. It offers a unique twin-lens reflex experience with interchangeable lenses.

Key Operations:

• Lens Mounting/Removal: Wind film advance crank, retract lens, unlock lens lock knob, detach lens. Reverse for mounting.
• Focusing Hood: Raise the rear of the hood to spring it open. Use the magnifier by pushing the sportsfinder flap. Turn the focusing knob to achieve a sharp image.
• Loading Film: Open back cover, pull upper spool change knob, insert spool, turn film advance crank until start mark is aligned. Close back cover firmly.
• Photographing: Focus, set shutter speed and aperture, press shutter release button. Wind film after each exposure. Clamp focusing knob for stability.
• Locking Shutter: Shift triangle mark on lock button to 'L' to lock the shutter, preventing accidental release during storage.
