Installation Guide for CS 1028

Turning on and off / Regulating

The control knob is used to turn on the burner and to regulate the strength of the flame.

• The gas supply is turned off
• Ignition setting
• Highest flame
• Lowest flame

The knob must only be turned left to turn the appliance on and right to turn it off.

If the knob is turned on without pressing it down first, turned clockwise to turn on, or turned counterclockwise to turn the combiset off, parts of the combiset might get damaged. The manufacturer cannot be held responsible for these damages.

Turning on

1. To turn on the burner, press the control knob down and turn it counterclockwise to the ignition position ① to turn on.
2. When the flame ignites, keep the control pressed in for 8-10 seconds, and then let go.
3. If the burner does not ignite or the flame goes out, turn the control knob to "●". Try again after a few seconds.
4. If the burner still will not ignite after the second attempt, turn the control knob to "o" and see "Frequently asked questions".

Adjusting the flame

The burner can be variably adjusted between the lowest and highest flame by turning the control knob.

Since the outer portion of the flame is much hotter than the center, the flame should be set so that its tips do not spread beyond the sides of the pan. Flame tips which extend beyond the sides of the pan are hazardous.

Turning off

Turn the control clockwise to ". This stops the flow of gas and the flame goes out.

Using the cooktop during a power failure

If there is an interruption to the electrical supply, the gas can be ignited using a match.

1. Press the control knob down and turn it counterclockwise to the ignition position.
2. While holding down the knob, light the gas at the burner with a match.
3. When the flame appears, keep the control knob pressed in for 8 - 10 seconds to allow the Ignition Safety Control to reach operating temperature.
