Manual for 11 930 810

Manual for 11 930 810

Brand: Miele

Category: Freezer

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 6:06 p.m.

Guide to the appliance

  • Status display: Shows the current status of the appliance.
  • Using the appliance: Basic operation and functions.
  • Settings mode: Access to various settings and options.
  • Adjusting the interior fittings: How to arrange shelves and drawers.
  • Ice- & PizzaBox: Information about specific storage compartments.
  • Tilting the top drawer: Instructions for using this feature.
  • Accessories supplied: List of included accessories.
  • Optional accessories: Information on available optional accessories.

Switching on and off

  • Before using for the first time: Initial setup steps.
  • Connecting the appliance: How to connect to power.
  • Switching on the appliance: Turning the appliance on.
  • Switching off the appliance: Turning the appliance off.
  • To note when switching off for longer periods of time: Preparations for extended shutdowns.

The correct temperature

  • Temperature display: Reading the current temperature.
  • Setting the temperature: Adjusting the desired temperature.
  • Possible temperature settings: Overview of available temperature levels.

Troubleshooting and error codes

Message Possible cause and solution
▲ is lit up red in the temperature display and an alarm is also sounding. The temperature alarm has been activated; the temperature in the freezer section has risen higher or fallen lower than the temperature set. Possible reasons for this include:
  • The appliance door has been opened too frequently.
  • A large quantity of fresh food has been placed in the freezer without switching on the SuperFrost function.
  • A prolonged power failure has occurred.
  • The refrigeration appliance has a fault.
Tap . The alarm message is confirmed: goes out and the alarm stops. The warmest temperature recorded in the refrigeration appliance will flash for about 1 minute in the display. Then the temperature display will change to the current temperature. You can exit from the flashing temperature display early:
  • Touch the temperature display. The warmest temperature display will disappear. The display will then revert to showing the current temperature in the freezer section.
Rectify the cause of the alarm. Depending on the temperature displayed, you should check whether food in the freezer has started to thaw or has defrosted. If it has, cook it before freezing it again.
D lights up red in the display and an alarm also sounds. There is a power failure: The temperature in the appliance over the last few days or hours has risen too high because of a power failure or interruption to the power supply. Tap . The fault message is confirmed: goes out and the alarm stops. The warmest temperature recorded in the refrigeration appliance will flash for about 1 minute in the display. Then the temperature display will change to the current temperature. You can exit from the flashing temperature display early:
  • Touch the temperature display. The warmest temperature display will disappear. The display will then revert to showing the current temperature. The appliance will go back to the last temperature setting when the power is restored.
Rectify the cause of the alarm. Depending on the temperature displayed, you should check whether food in the freezer has started to thaw or has defrosted. If it has, cook it before freezing it again.
lights up red in the display and a fault code F with numbers may appear. An alarm will also sound. There is a fault.
  • Tap on the display to switch the alarm off.
  • Contact Miele Customer Service.
To report the fault, you need the fault code and also the model identifier and serial number of your refrigeration appliance. You can access this information on the display.
  • To do this, touch on the display. The appliance data required will be shown on the display. Confirm with OK to exit the information display and the fault code will be shown again on the display.
The refrigeration appliance can be switched off directly from the fault-message display. There is an appliance fault: this display always has priority over any settings which have just been selected. An appliance fault has priority over any current door and/or temperature alarms displayed.
lights up red in the display and an alarm also sounds. There is a fault with the ice-cube maker.
  • Tap on the display to switch the alarm off.
  • Contact Miele Customer Service.
The ice-cube maker can also be switched off in Settings mode .
Problem
You cannot turn the ice cube maker on.		 Possible cause and solution
The appliance is not connected to the power supply or is not switched on.
  • Reconnect to the power supply and switch the appliance back on.
The refrigeration appliance or ice maker is not switched on.
  • Switch the refrigeration appliance and the ice maker on.
Problem
The ice maker is not producing any ice cubes.		 Possible cause and solution
The water supply has not been turned on or has not been vented.
  • Turn on the water supply.
  • Check that the water supply has been vented.
The ice maker drawer is not closed properly.
  • Push the drawer all the way in.
The appliance door has been opened too frequently, causing the compressor to turn on more often and the ice maker has iced up.
  • Only open the appliance door when necessary and for as short a time as possible.
The temperature in the freezer section is too high.
  • Select a lower temperature.
The water connection pressure is too low.
  • Check that the water connection pressure is between 21.7 and 90 psi (1.5 and 6.2 bar).
Remember that it can take up to 24 hours for the production of ice cubes to commence.
Problem
The ice cubes have an unpleasant odor or flavor.		 Possible cause and solution
The ice-cube maker is in constant use and needs to be cleaned regularly.
  • Rinse the ice-cube maker and water-intake pipe regularly. The first three batches of ice cubes should be thrown away and not consumed.
The ice-cube maker is rarely used. If you do not use it very often, ice cubes that are stored for a long period can absorb the taste and smell of other items.
  • Empty the ice-cube drawer if you are not going to use the ice-cube maker for a long period of time. Rinse the ice-cube maker and water-intake pipe regularly. The first three batches of ice cubes should be thrown away and not consumed.
There are unsealed food packages in the freezer section. Ice can absorb the taste and smell of unsealed food.
  • Store only sealed food in the freezer section.
The ice-cube drawer is dirty.
  • If necessary, clean the ice-cube drawer.
Problem
The interior lighting is not working.		 Possible cause and solution
The refrigeration appliance has not been turned on.
  • Turn the refrigeration appliance on.
Sabbath mode is switched on: the display is dark and the refrigeration appliance is cooling.
  • Tap on the black display. will appear on the display.
  • Tap .
  • Tap on the symbol in Settings mode . When Sabbath mode is switched off, the symbol will light up white.
To avoid overheating, the interior lighting switches itself off automatically after approximately 15 minutes if the appliance door is left open. If this is not the cause, there is a fault.
  • Contact Miele Customer Service.
