General Information

Repairs must be performed by trained technicians adhering to national, state, and local codes.
Observe all applicable laws, regulations, and accident prevention guidelines during servicing.
Comply with utility supply company regulations and safety standards.
Always disconnect the vacuum cleaner from the power supply before starting any service work.
Be aware that supply voltage may be present on some components even when the vacuum is switched off.
Never leave the vacuum unattended while plugged in. Turn off and unplug before opening the cover.
Perform a visual and operational check after completing work.

Cleaning and Care

Vacuums and Accessories: Clean with a damp cloth or a specialized plastic cleaner. Avoid abrasive or all-purpose cleaning solutions.
Dust Compartment: Clean with another vacuum, a dry cloth, or a brush. Regularly monitor the bag change indicator and filters, replacing them as needed.

Troubleshooting and error codes

Section	Cause	Remedy
3.1 Suction Power Is Too Low	Bag jammed between casing top and cover frame.	Replace bag. See Section 010-4.6.
	Floor attachment or suction hose blocked.	Clean the floor attachment or suction hose.
	Filter clogged.	Replace all filters. See Sections 010-4.7 through 010-4.10.
	Seal or sealing ring not seated correctly.	Check for correct seating. Reseat elbow or replace locking tabs as necessary.
3.2 Elbow Not Seated Correctly in the Suction Opening	The hygienic slide shutter slides in front of the suction opening.	Reseat elbow or replace locking tabs as necessary. Replace the slide shutter. See Section 020-4.9.
3.3 Elbow Blocked	The hygienic slide shutter slides in front of the suction opening.	Replace the slide shutter. See Section 020-4.9.
3.4 Appliance Always Operates at Full Power	Electronic in handle is defective.	Replace the suction hose with electronic; see Section 055-4.1.
3.4 Appliance Always Operates at Full Power	Poor contact between slip ring and electronic.	Replace the suction hose with electronic; see Section 055-4.1.
3.5 Appliance Cannot Be Switched On	Electronic in handle is defective.	Replace the suction hose with electronic; see Section 055-4.1.
3.5 Appliance Cannot Be Switched On	Poor contact between slip ring and electronic.	Replace the suction hose with electronic; see Section 055-4.1.
3.6 Power Level Cannot Be Adjusted	Electronic in handle is defective.	Replace the suction hose with electronic; see Section 055-4.1.
3.6 Power Level Cannot Be Adjusted	Poor contact between slip ring and electronic.	Replace the suction hose with electronic; see Section 055-4.1.
3.7 Electrobrush Cannot Be Selected	Electronic in handle is defective.	Replace the suction hose with electronic; see Section 055-4.1.
3.7 Electrobrush Cannot Be Selected	Poor contact between slip ring and electronic.	Replace the suction hose with electronic; see Section 055-4.1.
