Printer Setup Procedure

  1. Position the adjustable paper guides.
  2. Install the print paper.
  3. Install the ink ribbon.
  4. Connect the printer to a personal computer.

Paper Installation

  1. Attach paper flanges to print paper.
  2. Turn on the power.
  3. Open the printing unit.
  4. Remove the paper strip bin and open the door.
  5. Install the print paper into the unit.
  6. Feed the print paper.
  7. Close the door.

Ink Ribbon Installation

  1. Load ink ribbon into ink cassette.
  2. Place ink cassette into the printer.
  3. Close the printing unit.

Troubleshooting and error codes

ALARM PAPER RIBBON POWER Causes and Countermeasures Page
    Orange This printer is in standby mode.
Connect a USB cable to the printer when not connected.
It may take time that the printer is ready to print images after the image data is sent.		 7
16
Blinking   Green The printing unit is open.
Close the printing unit.		 7
Steady on Steady on Green A paper jam or a problem concerning the ink ribbon occurs.
Refer to "Overcoming paper jams."		 18
Blinking   Green The temperature of the thermal head is too high or too low.
Wait until the indication goes off. When the indicator stops blinking, the printer resumes printing automatically.		 7
  Steady on Green The ink ribbon which is not available to this printer is installed.
Replace the ink ribbon with a new one.
The actual combination of ink ribbon and print paper is inconsistent with the setting made by the personal computer.
Open the printing unit and confirm that the actual combination of ink ribbon and print paper is consistent with the setting made by the personal computer. After checking, close the printing unit.		 13-14
  Blinking Green The print paper or ink ribbon is not installed.
The print paper or ink ribbon is used up.
Install new print paper or ink ribbon.		 11-14
Blinking   Green Other errors 20
