Basic Operation Summary
This section outlines the fundamental steps for operating the CP-M1 Digital Color Printer.
Setup Procedure:
- Install the ink ribbon.
- Install the print paper.
- Connect the printer to a personal computer.
Ensure the printing unit is closed after completing setup.
Printing Process:
Before printing, turn on the printer and the personal computer. Install the printer driver on the PC. Then, connect the printer to the PC using a USB cable. The printer supports Hi-Speed USB (Ver. 2.0).
Maintenance:
Regular cleaning of ventilation inlets, thermal head, and platen roller is recommended for optimal performance and longevity. Procedures for ventilation inlet cleaning, thermal head cleaning, and platen roller cleaning are detailed in the manual.
Troubleshooting and error codes
| ALARM | PAPER/ RIBBON | DOOR | POWER | Causes and Countermeasures | Page |
|---|---|---|---|---|---|
| ● | ○ | ○ | ○ (Blinks slowly) | The printer is in the standby mode. The printer is in the power save mode. When the printer is idle for an extended period, it automatically enters the power save mode from the standby mode, reducing power consumption. It may take time that the printer is ready to print images after the image data is sent. |
7 |
| ● | ○ | ● | ○ | The printing unit is open. • Close the printing unit. • The paper strip bin is removed. • Attach the paper strip bin properly. |
7 |
| ● | ● | ○ | ○ | A paper jam or a problem concerning the ink ribbon occurs. • Refer to "Overcoming paper jams." |
16 |
| ● | ● | ○ | ○ | The ink ribbon which is not available to this printer is installed. • Replace the ink ribbon with a new one. |
10 |
| ● | ● | ● | ○ | The print paper or ink ribbon is not installed. The print paper or ink ribbon is used up. • Install new print paper or ink ribbon. |
10-12 |
| ● | ● | ● | ● | Other errors | 18 |
