Warranty Information

Contact your dealer for warranty information and service. Refer to the manufacturer's website for details.

Starting up the projector:
  1. Plug in the power cord and turn on the wall socket switch.
  2. Remove the lens cap.
  3. Press POWER to start the projector. The POWER indicator light will flash green and then stay green.
  4. (Optional) Rotate the focus ring to adjust image clearness.
  5. Wait for the cooling fans to stop before turning off if the projector is still hot.
  6. Wait at least 5 minutes before turning off after turning the projector on to maintain lamp life.
  7. Switch on all connected equipment.
  8. The projector will search for input signals. Press SOURCE to select manually if needed.
Using the menus:
  • Press MENU/EXIT to turn on the OSD menu.
  • Use arrow keys to navigate and MODE/ENTER to select/confirm.
  • Press MENU/EXIT twice to exit and save settings.

Troubleshooting and error codes

Problem Cause Remedy
The projector does not turn on. There is no power from the power cable. Plug the power cord into the AC inlet on the projector, and plug the power cord into the power outlet. If the power outlet has a switch, make sure that it is switched on.
Attempting to turn the projector on again during the cooling process. Wait until the cooling down process has completed.
No picture The video source is not turned on or connected correctly. Turn the video source on and check that the signal cable is connected correctly.
The projector is not correctly connected to the input signal device. Check the connection.
The input signal has not been correctly selected. Select the correct input signal with the SOURCE key on the projector or remote control.
The lens cover is still closed. Open the lens cover.
Blurred image The projection lens is not correctly focused. Adjust the focus of the lens using the focus ring.
The projector and the screen are not aligned properly. Adjust the projection angle and direction as well as the height of the unit if necessary.
The lens cover is still closed. Open the lens cover.
Remote control does not work The battery is out of power. Replace the battery with a new one.
There is an obstacle between the remote control and the projector. Remove the obstacle.
You are too far away from the projector. Stand within 8 meters (26 feet) of the projector.
The password is incorrect You do not remember the password. Please see "Entering the password recall procedure" on page 21 for details.
The LAN function cannot be used LAN control settings or LAN cable connection are problematic. Verify the LAN control settings. Please see "Configuring the LAN Control Settings" on page 34 for details. Make sure the LAN cables are properly connected.
The web page is not shown in the web browser or the web page is not responding. Reload the page to see the data after changing on the screen. If the page is not showing the modified data, check the IP address of projector and log-in again.
