Manual for Series 900

System Overview

The Series 900 family of servers and multi-user computers is based on the Motorola M88000 family of microprocessors and the VMEbus standard. These systems feature a modern, compact, modular design consisting of a CPU module, VME Expansion module, and SCSI Device Expansion Module.

Manual Organization

This manual is organized into five chapters and three appendices, covering:

• Chapter 1: Introduction - Overview and references.
• Chapter 2: CPU Module - Configuration, power supply, front panel, and LEDs.
• Chapter 3: VME Expansion Module - Configuration, power supply, backplane, and LEDs.
• Chapter 4: SCSI Device Expansion Module - Configuration, backplane, power supply, and termination.
• Chapter 5: Base and Crown - System base and crown information.
• Appendices: System Maintenance, Cables, and System Specifications.
