The WS2000 Wireless Switch provides a low-cost, feature-rich option for sites with one to six Access Ports. It combines wireless LANs (WLANs) and wired networks, acting as a WAN/LAN gateway and a wired/wireless switch. Key functions include managing access ports, configuring firewall security, wireless LAN security, and VPN security. The hardware includes a WAN port, six LAN ports (four with PoE), a serial port, and a CompactFlash slot. The software overview covers Operating System (OS) Services, Cell Controller Services, and Gateway Services.
Troubleshooting and error codes
| System Component | Debug Level | Log Message |
|---|---|---|
| Port Configuration | LOG_DEBUG | Register value received for Port [idx] = [register value] |
| Port Configuration | LOG_DEBUG | Register value to be set for Port [idx] = [register value] |
| Port Configuration | LOG_DEBUG | Writing Register values for Wan = [register value] |
| Port Configuration | LOG_DEBUG | Setting Wan port configuration. |
| Default Gateway | LOG_DEBUG | Deleting Default gateway Interface [interface name] |
| Default Gateway | LOG_DEBUG | Adding Default gateway: Executing command [cmd] |
| CF Format | LOG_DEBUG | CF format message sent ot msg task |
| IP Filter Module | LOG_DEBUG | IP Filtering is called from TRUNK OUTGOING context |
| IP Filter Module | LOG_DEBUG | Dropping packet |
| IP Filter Module | LOG_DEBUG | Allowing packet |
| IP Filter Module | LOG_DEBUG | IP Filtering is called before BCMC_LAN from TRUNK INCOMING context |
| IP Filter Module | LOG_DEBUG | IPF: Dropping packet |
| IP Filter Module | LOG_DEBUG | IP Filtering is called from TRUNK INCOMING context |
| IP Filter Module | LOG_DEBUG | IPF: Dropping packet |
| IP Filter Module | LOG_DEBUG | IP Filtering is called from WLAN[wlan-index]OUTGOING context |
| IP Filter Module | LOG_DEBUG | IPF: Dropping packet |
| IP Filter Module | LOG_DEBUG | IP Filtering is called from PS_Switch_Defrag_Data WLAN[wlan-index] INCOMING context |
| IP Filter Module | LOG_DEBUG | IPF: Dropping packet |
| IP Filter Module | LOG_DEBUG | IP Filtering is called from WLAN[wlan-index]OUTGOING context |
| IP Filter Module | LOG_DEBUG | IPF: Dropping packet |
| IP Filter Module | LOG_DEBUG | IP Filtering is called from WLAN[wlan_index]INCOMING context |
| IP Filter Module | LOG_DEBUG | "\"\"\"IPF: Dropping packet\"" |
| IP Filter Module | LOG_DEBUG | IP Filtering is called from BCMC_LAN WLAN[wlan_index]OUTGOING context |
| IP Filter Module | LOG_DEBUG | IPF: Dropping packet |
| IP Filter Module | LOG_DEBUG | IP Filtering is called from BCMC_ESS WLAN OUTGOING context |
| IP Filter Module | LOG_DEBUG | IPF: Dropping packet |
| IP Filter Module | LOG_DEBUG | Protocol mismatch |
| IP Filter Module | LOG_DEBUG | direction mismatch[incoming/outgoing] |
| IP Filter Module | LOG_DEBUG | Hash entry pointing to NULL |
| IP Filter Module | LOG_DEBUG | Packet Source IP [ip address] |
| IP Filter Module | LOG_DEBUG | Packet Destination IP [ip address] |
| IP Filter Module | LOG_DEBUG | Packet protocol [protocol number] |
| IP Filter Module | LOG_DEBUG | Packet port [port number] |
| IP Filter Module | LOG_DEBUG | Packet direction[incoming/outgoing] |
| IP Filter Module | LOG_DEBUG | Default Action |
| IP Filter Module | LOG_DEBUG | Action [Allowing/Dropping] packet |
| DynDNS Module | LOG_DEBUG | No Change in Hostname and WAN IP |
| DynDNS Module | LOG_DEBUG | DynDNS: Duplicate record |
| DynDNS Module | LOG_DEBUG | [function]: Adding Service and Interface record DONE |
| DynDNS Module | LOG_DEBUG | "DynDNS Status: [Status] IP [IP address], Hostname [hostname] " |
| Cell Controller Module | LOG_EMERG | Caught Signal [Number] Aborting with core dump! |
| Cell Controller Module | LOG_EMERG | Assertion failed. Aborting with core dump! |
| Cell Controller Module | LOG_EMERG | bind failure: address in use. Check |
| Cell Controller Utility Module | LOG_EMERG | Assert Fail File %s Line [Number]; Exiting file |
| Rogue AP Detection Module | LOG_EMERG | memory allocation failure! |
| Rogue AP Detection Module | LOG_EMERG | Memory allocation failure! |
| Security Policy Module | LOG_EMERG | Config read failure. File: %s Line: [Number] |
| Security Policy Module | LOG_EMERG | Couldn't init Security Policy for WLAN [Number] reverting to defaults i+1 |
| AP2AP Beaconing | LOG_EMERG | memory allocation failure! |
