Manual for E585

Brand: NEC

Category: Other

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 6:54 p.m.

Warranty Information

No specific warranty period is mentioned in the provided pages.

Press the power button on the remote control or press the power button located on the side of the display. The display will power on.

When in on mode, the Display operates as follows if no external signal is input.

When the external device is connected to the VGA terminal, the NO SIGNAL menu is displayed and 15 seconds later the Display switches to warming up mode.
In warming up mode, when the Display receives a signal from an external VGA device, it switches automatically to on mode.

Connect your PC, HDMI devices, USB devices, VGA/AUDIO devices, Component/AV devices, and SPDIF OUT using the appropriate cables as illustrated.

Use the side panel controls or the remote control to adjust volume, navigate menus, select input sources, and turn the display on/off.

Browse images, listen to music, or play videos from a USB device.

Symptoms	Items To Check And Actions To Follow
No power	Check to see if the display's AC power cord is plugged into the outlet. Unplug the display and after 60 seconds reinsert the plug into the outlet and power on the display.
No picture	Adjust the contrast and brightness settings.
Good picture but no sound	Increase the volume. Confirm that the display is not muted by pressing the Mute button on the remote control.
Good sound but poor color	Adjust the contrast, color and brightness settings.
Poor picture	Poor picture quality may occur when an activated S-VHS camera or camcorder is connected to your display and another peripheral at the same time. Switch off one of the peripherals. This may be caused by electrical interference. Power cycle the equipment.
Presence of a horizontal dotted line	This may be caused by electrical interference (e.g. hair-dryer, nearby neon lights, etc.). Power cycle the equipment by turning off and then turning back on.
Display not responding via the remote control	Determine if the batteries are working and replace batteries if necessary. Clean the remote control sensor lens on the display. If necessary, utilize the buttons located on the side of the display.
