Warranty Information

Warranty does not cover damage from improper installation, remodelling, or natural disasters.

Powering On/Off: Use the main power switch to ON and then use the Power button or remote to power the unit on or off. The indicator light shows the status: green for ON, red for OFF, amber for power save.

Selecting Video Source: Use the INPUT button to cycle through available inputs like DVI, HDMI, VGA, etc. The "COLOR SYSTEM" menu can be used for specific video formats.

Adjusting Picture: Access the OSD menu using the MENU button or remote. Adjustments for backlight, contrast, brightness, color, and picture mode are available. The "AMBIENT" modes automatically adjust backlight based on room lighting.

Using Remote Control: The wireless remote allows access to most functions, including input selection, picture adjustments, and menu navigation. Ensure batteries are correctly inserted and the remote is pointed at the sensor.

Connecting Equipment: Connect computers, DVD players, or other devices using the appropriate input terminals (DVI, HDMI, DisplayPort, VGA, etc.). Ensure power is off before making connections.

Network Control: The monitor can be controlled via LAN using an HTTP browser. Configure network settings and access control through a web interface.

Troubleshooting and error codes

Troubleshooting	No picture	Power Button does not respond	Image persistence	Image is unstable, unfocused or swimming is apparent	Image of component signal is greenish	LED on monitor is not lit	RED LED on monitor is blinking	Display image is not sized properly	Selected resolution is not displayed properly	No Sound	Remote Control is not available	"SCHEDULE"/"OFF TIMER" function is not working properly	Snowy Picture, Poor Sound in TV	Interference in TV	RS-232C or LAN control is not available
	• Signal cable fully connected. • Display card seated. • Main Power Switch ON. • Front Power Switch & Computer ON. • Supported mode selected. • Compatibility checked. • Signal cable connector checked.	• Unplug power cord, wait, then plug back in. • Check main Power Switch.	• LCD may experience Image Persistence. Avoid static images for long periods. • Turn off monitor for a period equal to display time. • Use moving images or screen saver.	• Signal cable fully attached. • Use OSD Image Adjust. • Compatibility and signal timings checked. • Change video mode to non-interlace, use 60Hz.	• Check DVD/HD input connector selected.	• Power Switch ON, cord connected. • Check main Power Switch. • Computer not in power-saving mode. • Power indicator OSD set to ON.	• Contact supplier. • RED LED blinks if inside temperature is high. Wait for it to cool.	• Use OSD Image Adjust. • Supported mode checked. • Consult display card/system manual.	• Use OSD Display Mode to confirm resolution. • Select corresponding option.	• Audio cable connected. • Mute OFF. • Volume up. • Computer supports audio via DisplayPort. • SURROUND OFF.	• Check batteries. • Batteries inserted correctly. • Remote pointing at sensor. • Remote Control Mode status checked. • Avoid direct sunlight/strong illumination.	• "SCHEDULE" disabled if "OFF TIMER" is set. • "OFF TIMER" resets if power is interrupted unexpectedly.	• Check antenna/cable connection. • Use new cable.	• Check shielding. • Move away from monitor.	• Check RS-232C or LAN cable. • Check "CONTROL" setting. • Check "ID=ALL REPLY" setting.
