Spec Sheet for P3200/P3300

Spec Sheet for P3200/P3300

Brand: NEC

Category: Printer

Document Type: Spec Sheet

Language: EN

Uploaded: Nov. 21, 2025, 8:43 p.m.

Manual Publish Date: 1995-10-05

Warranty Information

None

  • Print Method: Impact, 24-pin dot matrix, 2x12 staggered pin arrangement.
  • Type Styles: Courier, Prestige Elite WP, Quick Gothic, Draft Gothic, Helvetica PS, Times PS, Bold PS.
  • Dot Size/Spacing: 0.0079 in. (0.2 mm) for dot size; Vertical: 60, 80, 90, 120, 180, 240, or 360 dpi; Horizontal: 180 or 360 dpi.
  • Line Spacing: n/60-, n/180, or n/360-in. line spacing.
  • Resolution: 360 vertical x 360 horizontal dpi.
  • Receive Buffer: Parallel: 8.0 KB (with 0 characters); Serial: 16.0 KB (with 0 characters).
  • Paper Handling: Sheet guide (standard), push tractor (standard), sheet feeder (optional).
  • Dimensions: P3200: 17.3" W x 13.5" D x 6.3" H; P3300: 22.9" W x 13.5" D x 6.3" H.
  • Weight: P3200: 19 lb; P3300: 25 lb.
  • Interface: Industry-standard parallel, RS-232C serial (optional).
  • Power: 94 Watts/144 volt/amperes; 321 BTU.
  • Power Requirements: 115 Vac ±15%, 50/60 Hz.
  • Environmental Conditions: Operating temperature: 41° to 100° F; Storage temperature: 13° to 140° F.
  • Print Head Life: 150 million dots/wire.
  • Reliability: MTBF: 4000 hours; MTTR: 15 minutes.
  • Acoustic Noise: Regular mode: 52 dBA.

Troubleshooting and error codes

BLINKING LED(S) ERROR DEFINITION SOLUTION
Select Paper empty. Load Paper.
Select and Prestige Elite Sheet feeder paper jam. Remove jam and reload paper.
Select and Quick Gothic Sheet feeder installation error. Reinstall sheet feeder.
Select and Draft Gothic Paper path error. Check paper select lever.
Select and Helvetica P.S. RS-232C buffer overflow. Press SELECT to clear buff-er and re-send data.
Select and Times P.S. Printer is unable to accept downloaded data. Press SELECT to clear error condition. Change buffer capacity to 4 KB in menu mode.
Selected Type Style blinking * Printer is in copy mode. To exit this mode, set the copy control lever to a setting between 1 and 5.
Selected Type Style blinking ** Print head over heating. Printing resumes when print head has cooled.
Select and 10 (Pitch) Printer is in short adjust mode. To exit this mode, press SELECT.
Select and 12 or15 (Pitch) Mechanical error during operation. Check for paper or print head jam and reinitialize printer.
