Warranty Information
36-month warranty against defects in material and workmanship from the date of manufacture.
The LCD2-80 is an alphanumeric display module that acts as a Display Interface in Terminal mode. It features an 80-character backlit LCD, control switches for Acknowledge, Signal Silence, Drill, and System Reset, a time/date display, and a local piezo sounder. It connects to Notifier fire alarm control panels via EIA-485 and displays device type identifiers, custom alpha labels, and time/date information directly from the control panel. Up to 32 units can be connected on a single circuit, with a maximum distance of 6000 feet. It operates in conjunction with the control panel's CRT.
Troubleshooting and error codes
| LED | Color | Function |
|---|---|---|
| Alarm | Red | Indicates an Alarm condition on the FACP. This LED will remain lit until all alarm conditions have been cleared. |
| Supervisory | Yellow | Indicates a Supervisory condition on the FACP. This LED will remain lit until all supervisory conditions have been cleared. |
| System Trouble | Yellow | Indicates a Trouble condition on the FACP. This LED will remain lit until all trouble conditions have been cleared. |
| Point Disable | Yellow | Indicates that a point on the FACP has been disabled. This LED will remain lit until the point has been re-enabled. |
| Signal Silence | Yellow | Indicates that any or all silenceable outputs have been silenced. This LED will be lit until the outputs have resounded or a reset is performed on the FACP. |
| Other | Yellow | Indicates that an Other or Security event has occurred on the FACP. This LED will remain lit until all other and security events have been cleared. |
NOTE: The second and eighth LEDs are reserved for Future Use.
