Manual for NFS2-3030

Manual for NFS2-3030

Brand: Notifier

Category: Fire Alarm Systems

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 8:46 p.m.

Manual Publish Date: 2016-04-27

Warranty Information

This manual does not contain specific warranty period information.

  • Normal Standby Operation: Green POWER indicator lit steadily; FIRE ALARM, TROUBLE, and OTHER indicators off.
  • Alarm Condition: Red FIRE ALARM and/or Yellow OTHER indicator(s) lit; alarm signaling devices activated; option module activated; alarm information visible on LCD.
  • Alarm Reset: Press SYSTEM RESET after correcting alarm condition. Requires two presses if both Fire and MNS conditions are present.
  • Trouble Condition: Trouble indicator illuminates; silence audible signal by pressing ACKNOWLEDGE.
Switch Functions:
  • Acknowledge: Silences piezo sounder, changes flashing to steady, sends acknowledge message.
  • Signal Silence: Turns off all silenceable circuits, illuminates SIGNALS SILENCED indicator.
  • Drill (Alarm Signal On): Activates all silenceable circuits for fire alarms.
  • System Reset: Resets control panel.
  • Lamp Test: Tests LEDs and panel sounder.
LED Indicators:
  • Power: Green (primary power applied).
  • Fire Alarm: Red (flashes for alarms, steady after acknowledged).
  • Pre-Alarm: Red (flashes for pre-alarm threshold).
  • Security: Blue (illuminates for security alarm).
  • Supervisory: Yellow (flashes for supervisory/tamper, steady when acknowledged).
  • System Trouble: Yellow (flashes for troubles, steady when acknowledged).
  • Other Event: Yellow (flashes for MNS, CO, etc., steady when acknowledged).
  • Signals Silenced: Yellow (illuminates after Signal Silence pressed).
  • Point Disabled: Yellow (illuminates when points are disabled).
  • CPU Failure: Yellow (illuminates if microprocessor fails).
  • Controls Active: Green (illuminates when NFS2-3030 controls network primary display).
Audible Sounder:
  • Alarm: Continuous tone.
  • Trouble, Disable, Pre-alarm: Two beeps/sec.
  • Supervisory: Four beeps/sec.
  • Security: Eight beeps/sec.
Testing & Maintenance: Follow NFPA 72 and CAN/ULC-S536. Notify authorities before testing. Physically disconnect releasing devices. Perform operational checks and walk tests. Battery checks are crucial for system reliability.

Troubleshooting and error codes

ComponentStatus
CPU2-3030(CPU2-3030DC for Canada only)The green Power indicator will turn on when power is coming from the main power supply. The yellow Trouble indicator will turn on until the batteries are connected.
AMPS-24/E Main Power SupplyThe green AC indicator will turn on when AC is supplied. The yellow Trouble indicator will turn on until the batteries are connected.
Each Auxiliary Power SupplyThe yellow Trouble indicator will turn on because batteries are not connected.
