Brand: Panasonic
Category: Camcorder
Document Type: Manual
Language: EN
Manual for AG-3DP1G
Uploaded: Aug. 10, 2025, 12:43 a.m.
Warranty Information
The manual mentions a P2HD 5 Year Warranty Repair Program for registered users.
The manual provides instructions on setting up and operating the Panasonic AG-3DP1G camcorder. It covers features such as 3D recording, image settings, audio input/output, recording and playback functions, menu operations, and connecting to external devices. Safety precautions and maintenance are also detailed.
Troubleshooting and error codes
| Priority | Warning type | LCD indication | Tally lamp | WARNING lamp | Alarm tone | Warning description and recording/playback operation | Countermeasures |
|---|---|---|---|---|---|---|---|
| 7 | Error Camera section | WARNING cause indication*4 blinks red | Off | Off | No | An error in the camera section is detected. Operation continues, but abnormal shooting may occur. | Check the cause indication*4 and consult your distributor. |
| 8 | P2 card fully recorded | P2 FULL Blinks red | Blinks 4 times per second after completing recording | Lights after completing recording | Continuous tone after completing recording | No more space on P2 cards left for recording.Stop recording.*5 | Delete clips that are no longer needed or insert a new card. |
| 9 | Playback sync error | SYNC POSI FAILED Blinks white | Off | Off | No | The synchronization of clip position has failed. It may occur when the reference signal is unstable during 3D clip playback | Check the number and type of the clip. Or press the STOP button to stop playback, check the connection and/or the input signal, then restart playback. |
| 10 | Recording error | REC WARNING Cause indication*6 Blinks red | Blinks 4 times per second | Blinks 4 times per second | Intermittent tone 4 times per second | A recording error has occurred. The error may terminate recording. *7 | Turn the power off and then back on again and check recording and playback. Replace any P2 card that does not enable normal recording. |
