Warranty Information

Please contact the dealer where you purchased this unit or Panasonic if above operations are not possible due to malfunction.

  • Waterproof/Dustproof: Unit complies with IP58 rating, can operate underwater up to 3.0m for 30 minutes. Handle with care to maintain waterproofing.
  • Charging: Charge the built-in battery via USB before first use. Charging time is approx. 4h 30m.
  • Recording: Unit records in MP4 format. Use compatible microSD cards (microSD/microSDHC) with appropriate speed class ratings.
  • Wi-Fi Function: Connect to a smartphone or wireless access point for various functions including remote operation, live broadcasting, and playback on DLNA-compatible devices.
  • Basic Operation: Use the joystick to navigate menus and control the unit. Set date and time before recording.
  • Troubleshooting: Refer to the manual for issues like condensation, low sound, power problems, recording interruptions, and PC connectivity.

Troubleshooting and error codes

Problem Check points
The lens or LCD monitor fog up.
  • This is due to condensation. It is not a malfunction. Please refer to page 5.
The alert sound and shutter sound are low.
  • This is for ensuring the waterproof performance of this unit, and not a malfunction. Opening and closing the side cover will restore the original volume.
Power
This unit cannot be turned on.
  • Charge the battery again to ensure it is sufficiently charged. (→11)
This unit does not stay on long enough. Battery runs down quickly.
  • In cold places, the battery using time becomes shorter.
  • If the operating time is very short even after the battery has been recharged sufficiently, the battery has worn out. Consult with your dealer.
Recording
This unit arbitrarily stops recording.
  • Use a microSD card that can be used for motion picture recording. (→14)
  • The recordable time may have shortened due to the deterioration of the data writing speed or repeated recording and deletion. Using this unit, format the microSD card. (→20)
  • If you use a microSD card with a SD Speed Class Rating lower than Class 6 in [SLOW MOTION] (→31), recording may stop suddenly. (→14)
  • If you use a microSD card with a SD Speed Class Rating lower than Class 10 when [PIXELS / FRAME RATE] (→32) is set to [3840×2160/25p], recording may stop suddenly. (→14)
Colour balance of images is strange when recording in a place such as a gymnasium.
  • In a place with multiple light sources, such as a gymnasium or a hall, set the White Balance setting to ⚙ (Indoor 2). If you cannot record clearly with the (Indoor 2), set it with [CUSTOM]. (→35)
Recorded motion pictures flicker. Horizontal lines appear in recorded images.
  • If you record an image with [1280×720/100fps] or [848×480/200fps] in [SLOW MOTION], flickering or horizontal lines may appear under fluorescent lighting. (→32)
With a PC
When connected by the USB cable, this unit is not detected by the PC.
  • If this unit is turned off, this unit starts charging when it is connected to a PC.
  • After re-inserting the microSD card into this unit, reconnect the supplied USB cable.
  • Select another USB terminal on the PC.
  • Check the operating environment. (→72, 77)
  • Connect the supplied USB cable again after restarting the PC and turning on this unit again.
  • Even if you connect this unit to a PC, it does not recognise this unit as a card reader while a Wi-Fi mode is running. Move the joystick left to end the Wi-Fi mode, and re-connect the supplied USB cable.
When the USB cable is disconnected, an error message will appear on the PC.
  • To disconnect the USB cable safely, double-click the ⏏ icon in the task tray and follow the instructions on the screen. (Windows)
Cannot see the PDF operating instructions for HD Writer WE 2.0.
  • You will need Adobe Acrobat Reader 5.0 or later or Adobe Reader 7.0 or later to read the PDF operating instructions for HD Writer WE 2.0.
About the Wi-Fi function
Cannot connect to wireless access point or smartphone.
  • Read page 64 if the Wi-Fi connection cannot be established.
When looking at the recording screen or playing back an image on the smartphone, mosaic-like noise appears and the motion is not smooth.
  • Depending on the smartphone or radio wave conditions, when you play back a motion picture, mosaic-like noise may appear on the screen and the motion may not be smooth. (The images to be recorded are not affected.)
A motion picture file is created that is longer than the recording time.
  • Recording in [SLOW MOTION] (→31) will create a motion picture file that is longer than the recording time. For example, the playback time of a motion picture recorded in [848×480/200fps] (1/8 slow-motion) will be 8-times longer than the actual recording time. (→32)
This unit does not change to Playback mode.
  • When this unit is recording a motion picture, “Image App\" cannot change to Playback mode.
Files cannot be played back.
  • If a high-quality motion picture is copied to a smartphone, it may not be able to be played back on the smartphone. (→32)
This unit does not turn off, even after closing "Image App".
  • This unit can be turned off by tapping → [CAMERA FUNCTION] → [Camera power off] on the \"Image App\" screen.
I have forgotten the Login ID or Password for the "LUMIX CLUB".
  • Check the information in the login screen of \"LUMIX CLUB\". http://lumixclub.panasonic.net/eng/c/
Live broadcasting does not work even if live broadcasting is set.
  • Live broadcasting does not work when the clock setting is ahead of or behind the actual time. Set the clock correctly. (→17)
Others
If the microSD card is inserted in this unit, it is not recognised.
  • If the microSD card is formatted on a PC, it may not be recognised by this unit. Use this unit to format microSD cards. (→20)
