Warranty Information

Panasonic covers defects in materials and workmanship for one year on most parts and 90 days on labor.

  • The section on "Setups" explains how to set up the DVD video camera/recorder, battery pack, and set the date/time.
  • The section on "Basic Techniques" explains the basic operation of this DVD video camera/recorder - recording of movies and still images and playback of recorded images.
  • The section on "Advanced Techniques" explains settings on this DVD video camera/recorder for more advanced usage.
  • The section on "Using Disc Navigation" explains editing with Disc Navigation: Refer to this section when finalizing DVD-R disc and initializing DVD-RAM disc.
  • The section on "Connecting to Other Devices" explains how to connect to TV, another AV device and PC, and how to operate after connections.
  • "Subsidiary Information" includes an introduction to products sold separately, proper cleaning, and troubleshooting.
We want this manual to be as helpful as possible, so it includes two easy ways to find the information you need:
  • A quick index for the information you use most often (this page).
  • A detailed table of contents directing you to specific information quickly (page 8-9).
Get to know your DVD video camera/recorder by using this manual, and get to know Panasonic. We appreciate your business.

Troubleshooting and error codes

Symptom Cause and Correction Reference page
Focus is not correct. Is it difficult to use auto focus with your subject?
Focus manually.		 47
Does "MF" appear?
The DVD video camera/recorder is set to manual focus.
Focus the subject manually, or release manual focus.		 47
Is the diopter control correctly adjusted if you are using the viewfinder as a monitor?
Adjust the diopter control.		 40
In cases other than the above, set the power switch to "POWER OFF", and then set it to " VIDEO" or "PHOTO" again. 39
During playback
Pressing the REC button will not start recording. Is disc dirty?
Use soft, dry cloth to clean it.		 22
Pressing the playback button will not start playback. Has the image been recorded by devices other than this DVD video camera/recorder?
Playback of image recorded on devices other than this DVD video camera/recorder may be impossible on this DVD video camera/recorder.
Has scene been edited by applications other than Disc Navigation?
If the scene recorded on this DVD video camera/recorder is edited with applications other than Disc Navigation, playback may not be possible on this DVD video camera/recorder.		 86
86
No playback pic-ture appears on TV screen. Is TV input selector set correctly?
Some TVs have multiple video input jacks. Check whether the correct input was selected on TV to match the connected jacks. If the DVD video camera/recorder is connected to VCR, set its input selector to "external input (LINE)".
Is the DVD video camera/recorder connected to TV correctly?
Check the connections.		 89
88
Playback picture is momentarily interrupted. Is input selector of this DVD video camera/recorder set to "LINE"?
Change it to "CAMERA" mode.		 57
Poor playback pic-ture Is disc scratched or does dirt or fingerprint adhere to it?
Clean the disc.
Was the image input from analog VCR (VHS, 8 mm) and recorded?
The problem may be improved if a VCR equipped with TBC Circuit is used for playback.		 22
90
