Brand: Panasonic
Category: Digital Camera
Document Type:
Language: EN
Manual for DC-LX100M2
Uploaded: Aug. 9, 2025, 11:35 p.m.
Warranty Information
Panasonic provides a one-year limited warranty for the digital camera parts and labor.
Handling of the camera
Do not subject to strong vibration, shock, or pressure. Avoid using the camera under the following conditions, which may damage the lens, monitor, viewfinder, or external case. This may also cause the camera to malfunction or prevent recording.
- Drop or hit the camera.
- Sitting down with the camera in your pants pocket or forcing it into a full bag.
- Press hard on the lens or the monitor.
The camera is not dust resistant, splash resistant, or waterproof. Avoid using the camera in places with excessive dust or sand, or where water can come into contact with the camera.
About Condensation
Condensation occurs when the ambient temperature or humidity changes. Be careful of condensation since it causes lens, viewfinder and monitor stains, fungus and camera malfunction.
If condensation occurs, turn the camera off and leave it for about 2 hours. The fog will disappear naturally when the temperature of the camera becomes close to the ambient temperature.
Troubleshooting and error codes
| Problem | Possible Cause | Solution |
|---|---|---|
| The picture is not played back. There are no recorded pictures. | • Is the card inserted? | Insert a card. |
| • Is this a folder or picture which was processed in the PC? | It cannot be played back by this unit. It is recommended to use the software “PHOTOfunSTUDIO” (P68) to write pictures from PC to card. | |
| Set [Playback Mode] to [Normal Play]. | ||
| A Wi-Fi connection cannot be established. Radio waves get disconnected. Wireless access point is not displayed. | • Use within the communication range of the device to be connected. | Use within the communication range of the device to be connected. |
| • Is any device, such as microwave oven, cordless phone, etc., that uses 2.4 GHz frequency operated nearby? | Radio waves may get interrupted when used simultaneously. Use them sufficiently away from the device. | |
| • When the battery indicator is flashing red, the connection with other equipment may not start or the connection may be disrupted. (A message such as [Communication error] is displayed.) | Check the battery level. | |
| • If you place the camera on a metal table or shelf, the radio waves may be adversely affected. In such cases, you may not be able to establish a connection. | Move the camera away from the metal surface. | |
| About a wireless access point | • Check if the wireless access point to connect is in operating state. | Check if the wireless access point to connect is in operating state. |
| • Check the radio wave condition of the wireless access point. | Perform the connection closer to the wireless access point. Change the location and orientation of the wireless access point. | |
| • It may not display even if the radio waves exist depending on the setting of the wireless access point. | Turn off and on the wireless access point. If the wireless channel of the wireless access point cannot be set automatically, set it manually by selecting from channel 1 to 11. When the network SSID of the wireless access point is set not to broadcast, the wireless access point may not be detected. Enter the network SSID to start the connection or enable the SSID broadcast of the wireless access point. |
