Warranty Information

No specific warranty period is mentioned in this section of the manual.

Startup of Unit

Follow these steps for initial and subsequent operations:

  1. Connect the power plug.
  2. Turn on the power switch and battery switch.
  3. Press the alarm buzzer stop key (BUZZER) to silence any ringing alarms.
  4. Set the desired chamber temperature.
  5. Verify that the chamber temperature cools to the set point.
  6. Test the alarm functions using the ALARM TEST key.
  7. Load samples, ensuring adequate space for air circulation.

Important: Do not block air intake or exhaust vents. Arrange items for proper air circulation.

Operation After Power Failure

The freezer resumes operation with the previously set temperature due to nonvolatile memory.

Temperature Setting

  1. Press the SET key.
  2. Adjust temperature using shift keys.
  3. Press SET key again to confirm.

The setting mode auto-returns to display mode after 90 seconds of inactivity.

Troubleshooting and error codes

Malfunction Check/Remedy
The chamber is not cooled at all
  • Check the circuit breaker.
  • Check voltage (call electrician if low).
  • Ensure power switch is ON.
  • Reduce the load if too many items are stored.
  • Wait if the freezer is in defrost condition.
  • Move away from products emitting electric waves.
The cooling is poor
  • Check ambient temperature (too high?).
  • Ensure the door is closed firmly.
  • Remove frost build-up.
  • Input set temperature properly.
  • Ensure the freezer is not in direct sunlight.
  • Remove heat sources nearby.
  • Check rubber cap and insulation for access port.
  • Reduce load if too many unfrozen items are present.
  • Move away from products emitting electric waves.
When the unit does not accept changes of set-point temperature
  • Ensure the freezer is installed on a sturdy floor.
  • Level the unit with leveling feet.
  • Ensure nothing is touching the frame.
  • Wait if the unit is in the status immediately after start up.
Noise
  • The unit may make noise during high load conditions or immediately after startup due to compressor operation and refrigerant flow. This is normal.
