Manual for DP-8060 / 8045 / 8035
Uploaded: Nov. 21, 2025, 8:20 p.m.
Manual Publish Date: 2006-11-01
Warranty Information
Panasonic Digital Document Company makes no warranties or guarantees, express or implied, with respect to the machine.
Operating Instructions Summary
This manual provides essential information for the basic operation of the Panasonic DP-8060/8045/8035 Digital Imaging System. It covers key functions such as Copying, Printing, Network Scanning, and Facsimile/Internet Fax/Email.
Key Features and Operations:
- Copying: Instructions on placing originals on the ADF or platen glass, basic copy operations, and making a copy.
- Printing: Guidance on printing from a PC or Windows Applications.
- Network Scanning: Details on starting the Communications Utility and scanning documents to your PC.
- Facsimile/Internet Fax/Email: Procedures for managing the Address Book, sending and receiving documents via Facsimile, Internet Fax, or Email.
- Safety Information: Crucial warnings and precautions regarding power connection, handling, installation, and consumables to ensure safe operation and prevent hazards.
Always refer to the specific sections for detailed steps and important notes to ensure proper use of the machine.
Troubleshooting and error codes
| Troubleshooting Section | Page |
|---|---|
| Troubleshooting | 38 |
| Machine Care | 39 |
| User (U) / Error Codes | 40 |
| User Error Codes (U Codes) | 40 |
| Removing Misfed Paper | 41 |
| Locations/User Error Codes (J Codes) | 41 |
| System Console (Option) (A) | 42 |
| Paper Entry Area (B) | 43 |
| Paper Transport Area (C) | 44 |
| Paper Exit/Fuser Area (D) | 45 |
| Automatic Duplex Unit (ADU) (E) | 46 |
| Reverse Area (F) | 47 |
| 3000-Sheet Tray (LCT) (Option) (G) | 47 |
| 2-Bin Finisher (Option) (H) (DA-FS600/605) | 48 |
| 2-Bin Finisher (Option) (H) (DA-FS330) | 49 |
| 1-Bin Saddle-Stitch Finisher (Option) (H) | 50 |
| 2-Bin Saddle-Stitch Finisher only (Option) (I) | 51 |
| 1-Bin Saddle-Stitch Finisher (Option) (I/F) | 52 |
| i-ADF (J) | 53 |
