Manual for PBAM 224 A1
Uploaded: Nov. 21, 2025, 8:21 p.m.
Manual Publish Date: 2021-11-05
Warranty Information
Warranty is valid for 3 years from the date of purchase, covering material or manufacturing defects.
Starting the Engine:
1. Ensure the engine oil is at the correct level.
2. Engage the catch basket.
3. Sit on the driver's seat, depress the brake pedal, and engage the locking brake.
4. Set the mowing unit to "off" and the cutting height to the desired level.
5. Set the gear shift to neutral and the speed lever to "choke" (for cold engines) or "fast" (for warm engines).
6. Turn the ignition key to "Start" until the engine runs, then set the speed lever as needed.
Mowing:
1. With the engine running and mowing unit engaged, slowly release the brake pedal to start moving.
2. Use the speed lever to accelerate.
3. To stop, depress the brake pedal.
Important Safety Notes:
- Always check the mowing area for foreign objects.
- Do not mow on slopes steeper than 10°.
- Always wear protective gear.
- Never operate with a damaged mowing blade.
- Keep bystanders and animals at a safe distance.
- Disengage the mowing unit and engine before performing any maintenance or checks.
Troubleshooting and error codes
| Problem | Possible Cause | Solution |
|---|---|---|
| Engine does not start | Fuel tank empty | Fill fuel tank |
| Ignition key not turned correctly | Turn ignition key correctly | |
| Mowing unit engaged | Disengage mowing unit | |
| Locking brake not engaged | Engage locking brake | |
| Engine stops during operation | Fuel tank empty | Fill fuel tank |
| Overheating | Allow engine to cool down | |
| Mowing unit clogged | Clean mowing unit | |
| Machine vibrates unusually strongly | Damaged or unbalanced mowing blade | Sharpen or replace mowing blade |
| Loose parts | Check and tighten all screws and connections | |
| Mowing blade does not stop quickly | Blade stopping device faulty | Contact customer service or specialist workshop |
| Tipping risk on slopes | Full catch basket | Empty catch basket before it is full |
| Driving too fast or sideways on slopes | Drive slowly, lengthwise, and avoid abrupt changes in speed or direction |
