Manual for PWS 20 C2

Name: Manual for PWS 20 C2
Brand: PARKSIDE
Availability: InStock

Brand: PARKSIDE

Category: Home Appliances

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 6:19 p.m.

Warranty Information

This appliance comes with a 3-year warranty from the date of purchase.

Switching the vacuum cleaner on/off: Connect the mains plug. Move the On/Off switch (A 2) to the "I" position for permanent operation, and to the "O" position to switch off.

Washer function: Turn the appliance on. Move the pump switch (3) to position "1" to switch on. Move it to "O" to switch off. Turn the appliance off after use.

Dry vacuuming: Use with a paper filter bag (12) or a fine dust filter bag (optional). Ensure the filter bag is correctly fitted.

Wet suctioning: Always attach the water tank (19). Place the foam filter (11) onto the filter basket (4a). Insert dry filters only. Twist the edge of the filter slightly and roll it back. To drain, place the suction hose (16) into the water tank and suction up water. Empty the dirt container immediately after use.

Carpet cleaning: Use with the upholstery washer nozzle (A 23) or the hard surface washer nozzle (A 24). Attach the nozzle, then push the trigger on the handle (15a) to spray. Move in strokes, overlapping for thorough cleaning.

Troubleshooting and error codes

Problem	Possible Cause	Troubleshooting
Device does not start	No mains voltage	Check socket, mains cable, plug, and fuse; consult an electrician if necessary.
	On/Off switch (2) defective	Repair by customer service.
	Brushes worn out	Repair by customer service.
	Motor defective	Repair by customer service.
Low or no suction power	Suction hose (16) or nozzles (20-24) blocked	Clear blockages and obstructions.
	Air regulation on handle (15) open	Close air regulation.
	Container (7) open	Close container.
	Container (7) full	Empty container.
	Filter (11/12) full or clogged	Empty, clean, or replace filter.
Device does not shut off	Float in filter basket (4a) not moving	Free the float.
	Float in filter basket (4a) defective	Repair by customer service.
	Float in filter basket (4a) not moving	Free the float.
	Float in filter basket (4a) defective	Repair by customer service.
Dust or dirt blown out of the device	Filter (11/12) not installed or incorrectly installed	Install missing filter or check correct seating of the filter.
