Manual for PD-F605
Uploaded: Nov. 21, 2025, 8:16 p.m.
Warranty Information
Contact your nearest Pioneer authorized service center or dealer for warranty service.
HERE'S WHAT YOU CAN DO!
- Program and play your favorite discs from among the 25 discs loaded in the player (Custom function).
- Immediately access and play your favorite tracks (Best Selection Memory function, up to 15 tracks).
- Easy access to recently played discs (Previous Disc Scan function).
- To listen in order from the first track: Press POWER, load discs, close hood, press play.
- To select the disc and track: Use digit buttons to select disc, press DISC SET. Use digit buttons to select track, press TRACK SET.
- To select a play mode (ALL, SINGLE, CUSTOM): Press MODE during play or stop.
- To stop play: Press ■.
- To pause play: Press ►/II.
- To skip to another track: Tap ►►►► or ◄◄◄◄.
- To fast forward/reverse: Hold down ◄◄◄◄/►►►►►►.
- CUSTOM playback: Program and play only desired discs.
- RANDOM play: Selects tracks at random.
- REPEAT play: Repeat one track, all tracks, or custom tracks.
- PROGRAM play: Program tracks/discs in a desired order.
- BEST button: Store favorite tracks (one-touch memory).
- PREVIOUS button: Scan discs listened to recently.
- HI-LITE scan: Scan 10 seconds of each track.
- TIME button: Check disc/track elapsed time, remaining time, and total time.
Troubleshooting and error codes
| Symptom | Probable cause | Remedy |
| No sound | • Output cables are connected incorrectly or loosely. • Incorrect operation of stereo amplifier. • Pin plugs and/or amplifier terminals are dirty. • Player is in pause mode. • The disc is loaded with the label side leftward. |
• Connect properly. • Check the settings of amplifier switches and sound volume controls. • Clean away dirt. • Press or II. • Reload the disc with the label side rightward. |
| When playback is started, it stops immediately. | • Disc is inserted in the wrong way. • Smudges, etc., on the disc. |
• Insert the disc correctly with the label side rightward. • Clean the smudges from the disc and then play it again. |
| Pause or stops during playback. | • Dead batteries. • Obstruction between player and remote control unit. |
• Replace batteries. • Relocate remote control unit or remove obstruction. |
When an abnormality is detected during operation of the unit, an error message (service No.) appeares on the units display automatically. Treat the error by following the instructions in "Countermeasures".
| Display on the unit | Service No. | Unit Status | Countermeasures |
| Service No. | U1 | The disc may not be loaded properly in the rack. | • Reload the discs properly. (Insert one disc only in a slot.) • Check if there is a foreign object attached onto the disc. • Check if there is a foreign object in the rack. |
| DISC TRACK MIN SEC | |||
| Service No. | U2 | There is an operation error in the mechanical section. | • Check if there is a foreign object in the rack. • Unplug the power cord then plug it in again. |
If the same display appears again, there may be an error in the mechanical section. When requesting servicing, please also let us know the service number displayed on the unit.
