Brand: PIONEER
Category: Stereo Receiver
Document Type: Parts/Service
Language: EN
Parts/Service for AVIC-F700BT/XS/UC
Uploaded: Nov. 21, 2025, 6:13 p.m.
Manual Publish Date: 2008-05-01
Warranty Information
Warranty information is not explicitly detailed in this section of the manual.
- Product Safety: Conforms to regulations, use specified parts, do not modify without instructions, ensure proper soldering, secure all connections, correct wiring, no internal debris, check power cord, ensure safe environment.
- Adjustments: Perform to maintain original performance as per manual instructions.
- Lubricants, Glues, Replacement Parts: Use specified substances and apply properly.
- Cleaning: Clean optical pickups, tape heads, lenses, and mirrors for optimal performance.
- Shipping mode and Shipping screws: Set shipping mode or install screws before shipment as specified.
Troubleshooting and error codes
| No. | Procedures | Item to be confirmed | |
|---|---|---|---|
| 1 | Confirm whether the customer complain has been solved. If the customer complain occurs with the specific media, use it for the operation check. | The customer complain must not be reappeared. Display, video, audio and operations must be normal. | |
| 2 | CD | Play back a CD. (Track search) | Display, audio and operations must be normal. |
| 3 | FM/AM tuner | Check FM/AM tuner action. (Seek, Preset) Switch band to check both FM and AM. | Display, audio and operations must be normal. |
| 4 | GPS positioning | Connect GPS antenna to the product, and check whether the current location is correct. | Current location must be correct. Display and operations must be normal. |
| 5 | Map display Touch-panel operation Remote-control operation |
Check functions of map scale change and map scroll. | Display and operations must be normal. |
| 6 | data added during the operating check. | Make sure to delete data added during the operating check. | |
| 7 | Appearance check | Check whether no media (CD etc.) is inside the product. | The media used for the operating check must be ejected. No scratches or dirt on its appearance after receiving it for service. |
Items to be checked regarding video
| Block-noise |
| Horizontal noise |
| Dot noise |
| Disturbed image (video jumpiness) |
| Too dark |
| Too bright |
| Mottled color |
Items to be checked regarding audio
| Distortion |
| Noise |
| Volume too low |
| Volume too high |
| Volume fluctuating |
| Sound interrupted |
