Installation Guide for PEL00590
Uploaded: April 20, 2026, 7:43 p.m.
- The button initiates a timed power supply for a set period.
- Power is cut at the end of the cycle, irrespective of further button presses.
- After the timed cycle ends and power is cut, the button can be pressed again to restart the timer.
Troubleshooting and error codes
| DIP SWITCH SETTING | TIMER FUNCTION | |||
|---|---|---|---|---|
| 1 | 2 | 3 | 4 | |
| 0 | 0 | 1 | 0 | 2 seconds to 50 seconds |
| 1 | 0 | 1 | 0 | 50 seconds to 20 minutes |
| 1 | 1 | 1 | 0 | 20 minutes to 70 minutes |
| 1 | 1 | 0 | 0 | 70 minutes to 2 hours |
| - | - | - | 1 | Timer function disabled |
