Manual for RDC-2E
Uploaded: Aug. 9, 2025, 11:56 p.m.
Warranty Information
One-year limited warranty covering defective parts, excluding damage from misuse or accidents.
Basic Operation
Preparing the Camera: Insert batteries and memory card (if applicable). Ensure batteries are correctly inserted with proper polarity. Initialize new memory cards.
Recording: Slide the main switch to [REC]. Select the destination drive (internal memory or memory card). Choose image quality (F, N, or E). Compose the shot using the viewfinder. Half-press the shutter release button to focus, then fully press to take the picture.
Playback: Slide the main switch to [PLAY (PC)]. Select the desired memory drive. Use FWD/REV buttons to select an image and press the shutter release to view.
Erasing Images: In playback mode, press the REC MODE/ERASE button to enter erase mode. Select the image and press the shutter release to erase it. Initialization erases all images.
Troubleshooting and error codes
| Problem | Probable Cause | Remedy | Reference page |
|---|---|---|---|
| No power | Batteries not positioned properly or are depleted. AC Adapter not connected properly. Auto Power-Off system shut down the camera. | Reposition batteries, replace batteries, or reconnect AC Adapter. Touch shutter release lightly or turn on power. | P.11, P.13 |
| Fails to record picture | Batteries not inserted properly or depleted. Power is off or in playback mode. Shutter release button not fully pressed. Internal memory full. Memory card issues (not inserted, not initialized, write-protected, full, expired). Self-timer mode selected. | Correct battery insertion/replacement. Set to [REC]. Fully press shutter release. Delete/copy images. Insert/initialize/enable memory card. Cancel Self-timer mode. | P.11, P.23, P.29, P.30, P.50, P.16, P.38 |
| Auto-focus does not focus on subject | Lens is dirty. Subject not in center of Auto-focus frame. Difficulty focusing. | Clean lens. Use Focus Lock or LIVE monitoring. Use Focus Lock. | P.1, P.39, P.40 |
| Actual image differs from viewfinder | Subject too close. | Use LIVE monitoring or macro shooting. | P.40, P.42 |
| Picture is too bright/dark | Image over/underexposed. | Compensate exposure with EV button. | P.32 |
