Delivery and Dealer Service
Pre-delivery service
1. Top up battery with acid and recharge for four hours.
2. Fit the steering wheel, tow plate, and where appropriate other parts.
3. Adjust cutting unit:
- Adjust lift springs (effective weight of cutting unit should be 12–15 kg (26.5-33 lb), or set to maximum lift if brush is to be fitted). (Only applies to BioClip and Combi.)
- Adjust cutting unit so that rear edge is about 2–4 mm (1/8") higher than front edge.
- Adjust cutting unit height setting so that cutting height limit is 5 mm (3/16") above the frame of the unit at the lowest cutting height.
4. Check that engine has correct amount of oil.
5. Check that the right amount of oil is in the transmission. (Not Rider 11)
6. Check and adjust tyre pressure (60 kPa/0.6 bar/8.5 PSI).
7. Connect battery.
8. Fill with fuel and start engine.
9. Check that machine does not move in neutral. (Not Rider 11)
10. Check:
- Forward drive.
- Reverse drive.
- Operation of blades.
- Seat safety switch.
- Lift lever safety switch.
11. Check engine revs 2 900 - 3 100 rpm. Rider 16, 2003- model, 2 800-3 000 rpm.
12. Tell customer about:
- Need and benefits of following the service schedule.
- Need and benefits of having machine serviced every 300 hours.
- The effects of maintenance on the machine's second-hand value.
- Applications for BioClip and Combi.
13. Complete proof of sale, etc.
After first 5 hours
1. Change engine oil.
Troubleshooting and error codes
| Engine will not start | Starter motor does not turn the engine | No spark from spark plug | Incorrect fuel supply |
|---|---|---|---|
| Discharged battery | Starter motor and/or cable connection defective | Heavily burnt electrodes | Fuel tank empty |
| No contact on starter relay | Bad ignition cable connection | Fuel stop valve does not open | |
| Spark plug short circuited | No fuel to the carburettor | ||
| Defective ignition coil |
| Engine starts but does not run satisfactorily | Engine runs unevenly or lacks power | Engine overheating |
|---|---|---|
| Ignition fault | Defective spark plug | Wrong fuel used. Fuel too old |
| Incorrect ignition setting | Heavily worn or blocked | Low octane value after long period of storage |
| Diode fault (V-twin engine) | Replace the diode | |
| Fuel fault | ||
| Incorrect heating value | Blocked air filter | |
| Incorrect contact gap | Ignition fault | |
| Incorrect pre-ignition position | Defective carburettor | |
| Check and adjust the contact gap | Insufficient cooling | |
| Adjust the pre-ignition | ||
| Fill the fuel tank | ||
| Defective pre-ignition | ||
| Diode fault (V-twin engine) | ||
| Incorrect setting | ||
| Replace the diode | ||
| Correct the setting | ||
| Spark plug has wrong heating value | ||
| Incorrect heating value | ||
| Tank ventilator blocked | ||
| Dirty fuel filter | ||
| Dirt in fuel pipe | ||
| Pinched or leaking fuel pipe | ||
| Replace fuel | ||
| Change the filter | ||
| Clean or replace the fuel pipe | ||
| Defective carburettor | ||
| Correct the carburettor setting | ||
| Clean the carburettor with compressed air | ||
| Blocked needle | ||
| Choke on | ||
| Check choke wire and choke valve | ||
| Engine damage | ||
| Carry out compression test | ||
| Overloading | ||
| Change operating technique | ||
| Partly or fully blocked needles and diffuser jets | ||
| Too low or no oil in the engine | ||
| Fill with right quantity and quality of oil | ||
| Blocked cooling fins or air intake | ||
| Clean off dirt and leaves | ||
| Cooling fan damaged | ||
| Change the fan and clean the fan cover |
| Machine runs slowly, lacks power or no drive at all | No machine drive in either direction | Drive belt slips | Key/keys missing or damaged | Hydrostatic transmission | Brakes applied |
|---|---|---|---|---|---|
| Drive belt worn or covered in oil and dirt | Drive belt's adjuster pulley defective | Engine shaft's pulley | Wheel hub, axle | Spline on input axle in the transverse axle damaged | Input shaft does not drive the hydraulic pump |
| Clean or replace the drive belt | Broken spring. Replace Lever jams. Lubricate | Replace the key. Inspect the axle and pulley for damage | Replace the key. Inspect the axle and pulley for damage | Repair or replace the transverse axle | Repair or replace the transverse axle |
| Defective pump components or differential parts | Blocked oil filter | ||||
| Low oil level in the hydrostatic transmission or tank | Lever for "bypass valve" partly extended | ||||
| Defective accelerator | Tubular pin in regulating axle sheared off. Replace | ||||
| Control incorrectly adjusted or damaged. Replace and adjust | Key on transverse axle broken | ||||
| Repair or replace the transverse axle | Damage inside transverse axle | ||||
| Brakes incorrectly adjusted or seized. | |||||
| Low oil level in the hydrostatic transmission or tank | |||||
| Lever for "bypass valve" partly extended | |||||
| Move lever to the drive position | |||||
| Tubular pin in regulating axle sheared off. Replace | |||||
| Control incorrectly adjusted or damaged. Replace and adjust | |||||
| Key on transverse axle broken | |||||
| Repair or replace the transverse axle | |||||
| Brakes incorrectly adjusted or seized. | |||||
| Lubricate the brake links. Adjust |
| Engine slows with heavy load | Abnormal noise in transmission | Defective engine | Defective transmission | Drive belt | Hydrostatic transmission's cooling fan | Pulley on hydrostatic transmission's input shaft | Hydrostatic transmission | Bypass valve |
|---|---|---|---|---|---|---|---|---|
| Engine speed drops | Drive belt for transverse axle | Transmission overheated | Oil level too low | Check the belt tensioning mechanism | Worn belt | Damaged impeller or runs against foreign object | Pulley loose or damaged | Oil level too low |
| Repair the engine | Belt worn or oily | Clean or replace the belt | Adjust the belt | Stop and let the transmission cool down. Clean the cooling fins. | Fill engine oil SAE 10W/30 to correct level | Lubricate the bearing or replace the belt adjuster | Replace the belt | Clean or replace the fan |
| Tighten or change the pulley | Fill engine oil SAE 10W/30 to correct level | Change the oil filter | ||||||
| Repair |
| Brakes do not work satisfactorily | The machine moves while in neutral | Difficulty in changing gear | The machine cannot be towed or pushed |
|---|---|---|---|
| Brake linkage | Brake lining | Hydrostatic transmission | Accelerator |
| Damaged or incorrectly adjusted | Worn or saturated in oil | Internal fault on e.g. gear shift axle | Incorrectly adjusted or seized |
| Change linkage and adjust to right setting | Change brake lining | Repair or replace the hydrostatic transmission | Lubricate and adjust |
| Bypass valve | Internal fault on e.g. gear shift axle | ||
| Incorrectly adjusted or seized | Internal fault in the hydrostatic transmission | ||
| Bypass valve only partly activated | |||
| Linkage damaged or seized | |||
| Internal fault in the hydrostatic transmission | |||
| Repair or change the hydrostatic transmission | |||
| Oil level too low | |||
| Fill engine oil SAE 10W/30 to correct level | |||
| Bypass valve only partly activated | |||
| Put out the control fully | |||
| Linkage damaged or seized | |||
| Internal fault in the hydrostatic transmission | |||
| Replace damaged parts. Adjust | |||
| Repair or change the hydrostatic transmission |
