Manual for HT-WX70

Manual for HT-WX70

Brand: SAMSUNG

Category: Home Cinema

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 7:31 p.m.

Warranty Information

Samsung offers a limited one-year parts and labor warranty for this product.

  • Connect speakers and power cord.
  • Use remote control to operate TV and Home Theater.
  • Load disc into tray, press DISC SKIP to select, then PLAY/PAUSE.
  • Use playback functions like Skip, Fast/Slow Playback, Zoom, etc.
  • Connect external components via AUX or HDMI.
  • Tune into radio stations using FM/XM buttons.
  • Access settings for Audio, Video, Sound Field, and more.
  • Use USB Host for media playback from USB devices.
  • Troubleshoot issues using the provided chart.

Troubleshooting and error codes

Symptom Check/Remedy
Disc tray does not open.
  • Is the power cord plugged securely into the outlet?
  • Turn off the power and then turn it back on.
Playback does not start.
  • Check the region number of the DVD.
  • DVD discs purchased from abroad may not be playable.
  • CD-ROMs and DVD-ROMs cannot be played on this DVD player.
  • Make sure that the rating level is correct.
Playback does not start immediately when the Play/Pause button is pressed.
  • Are you using a deformed disc or a disc with scratches on the surface?
  • Wipe the disc clean.
Sound is not produced.
  • No sound is heard during fast playback, slow playback, and step motion playback.
  • Are the speakers connected properly? Is the speaker setup correctly customized?
  • Is the disc severely damaged?
Sound can be heard only from a few speakers and not all six.
  • When listening to a CD or radio, sound is output to the front speakers (L/R) only. Select "PRO LOGIC II" by pressing the remote control to use all six speakers.
  • Make sure that the DVD disc is 5.1-CH compatible.
  • If you set C, SL, and SR to NONE in the speaker mode in the audio setup of the setup screen, no sound is heard from the center speaker and the front left and right speakers. Set C, SL, and SR to SMALL.
Dolby Digital 5.1 CH Surround Sound is not produced.
  • Is there "Dolby Digital 5.1 CH" mark on the disc? Dolby Digital 5.1 CH Surround Sound is produced only if the disc is recorded with 5.1 channel sound.
  • Is the audio language correctly set to DOLBY DIGITAL 5.1-CH in the information display?
The remote control does not work.
  • Is the remote control being operated within its operation range of angle and distance?
  • Are the batteries exhausted?
  • Have you selected the mode(TV/DVD) functions of the remote control (TV or DVD) correctly?
Disc is rotating but no picture is produced.
  • Is the TV power on?
  • Are the video cables connected properly?
  • Is the disc dirty or damaged?
  • A poorly manufactured disc may not be playable.
Picture quality is poor and picture is shaking.
  • A poorly manufactured disc may not be playable.
Audio language and subtitles do not work.
  • Audio language and subtitles will not work if the disc does not contain them.
Menu screen does not appear even when the menu function is selected.
  • Are you using a disc that does not contain menus?
Aspect ratio cannot be changed.
  • You can play 16:9 DVDs in 16:9 WIDE mode, 4:3 LETTER BOX mode, or 4:3 PAN SCAN mode, but 4:3 DVDs can be seen in 4:3 ratio only. Refer to the DVD disc jacket and then select the appropriate function.
The main unit is not working. (Example: The power goes out or strange noise is heard.)
  • Turn off the power and hold the STOP button on the main unit for longer than 5 seconds.
  • Using the RESET function will erase all stored settings. Do not use this unless necessary.
The DVD player is not working normally.
  • While "NO DISC" message appears on the display of main unit, hold the main unit's STOP button for longer than 5 seconds. "INITIAL" appears on the display and all settings will return to the default values.
  • Press the POWER button.
  • Using the RESET function will erase all stored settings. Do not use this unless necessary.
The password for rating level has been forgotten.
  • Press the POWER button.
  • Using the RESET function will erase all stored settings. Do not use this unless necessary.
Can't receive radio broadcast.
  • Is the antenna connected properly?
  • If the antenna's input signal is weak, install an external FM antenna in an area with good reception.
<CHECK ANTENNA> is displayed.
  • XM Antenna Jack and the XM Antenna is not properly connected. Check the connections.
<ON SIGNAL> is displayed.
  • Reposition your XM Antenna.
<OFF AIR> is displayed.
  • The selected channel is not currently broadcasting.
Receiving only XM channel 0 and channel 1.
  • XM Antenna is not activated.
  • Access the website at "http://activate.xmradio.com" with a credit card to sign up.
