Warranty Information

Refer to the warranty information provided with the product for specific details.

1. **Safety:** Read all safety warnings and precautions before operating the appliance. 2. **Preparation:** Ensure the gas and electrical supply are compatible with the appliance's rating plate. Ensure good ventilation. 3. **Installation:** Install the appliance in accordance with regulations, ensuring proper gas and electrical connections. Do not install on marine vessels or RVs. Ensure adjacent furniture can withstand heat. 4. **Usage:** Use only for cooking, not for heating. Keep children and pets away. Do not spray aerosols nearby. Do not use with wet hands. Turn control knobs to 'OFF' when not in use. 5. **Cleaning & Maintenance:** Disconnect from mains and allow to cool before cleaning. Use non-abrasive cleaners. 6. **Troubleshooting:** Refer to the troubleshooting table for common issues like ignition problems or gas smell. Contact customer care if the issue persists. 7. **Gas Conversion:** Conversion between gas types must be done by a qualified technician. 8. **Gas Connection:** Ensure correct connection to the gas supply, using appropriate pipes and connectors. 9. **Electrical Connection:** Ensure the appliance is properly earthed and connected to the correct voltage supply. 10. **Burner Features:** Understand the different burner types and their heat inputs and flow rates. 11. **Positioning:** Install with adequate clearance from walls and combustible materials. 12. **Application for Service:** Contact Samsung customer care for any issues or questions.

Troubleshooting and error codes

Problem Probable cause Solution
Not ignited No Spark. Check the electricity supply
The burner lid is badly assembled. Assemble the lid correctly.
The middle valve is closed. Open the middle valve completely.
Badly ignited The middle valve is incompletely opened. Open the middle valve completely.
The burner lid is badly assembled. Assemble the lid correctly.
The ignition plug is contaminated with alien substance. Wipe such alien substance with dried clothing.
The burners are wet. Dry the burners lids carefully.
Noise made when combusted and ignited The holes in the flame spreader are clogged. Clean the flame spreader.
The burner lid is badly assembled. Assemble the burner lid correctly.
Fire off while using The flame supervision device is contaminated with alien substance. Clean the flame supervision device.
The holes in the flame spreader are clogged. Clean the flame spreader.
Yellow Flame Different gas is used. Check the gas used.
Unstable Flame The burner lid is badly assembled. Assemble the burner lid correctly.
Gas Smell A gas tap has been left on. Check to see if any gas taps are on.
There may be a leak between the coupling and the gas bottle. Make sure that the connection is airtight.
