Warranty Information
SECA warrants the product free from defective material and workmanship for one year.
Main Features
- SBS function: Produces rich, deep bass tones for powerful sound.
- Random function: Allows tracks to be played in random order.
- Album function (MP3-CD Only): Enables easy browsing and searching of tunes by album name, song title, and artist.
- ESP function: Provides high resistance to shock or vibration, keeping sound undisturbed (up to 120 seconds for MP3, 45 seconds for CD).
- Last Memory function: Allows resuming playback from the point where it was last stopped.
CD Playback
- Slide the OPEN button to open the door and insert a CD.
- Press the Play/Pause button to begin playback.
- Press the Stop button to stop playback.
- Press the Play/Pause button to temporarily pause playback and again to resume.
MP3-CD Playback
- Slide the OPEN button to open the door and insert an MP3-CD.
- Press the Play/Pause button for playback (unit scans for tracks first).
- Press the Stop button twice to stop playback.
Troubleshooting and error codes
| Problem | Check |
|---|---|
| Unit has no power. | • Did you insert the battery with the correct polarity? • Are the batteries drained? • Is the AC adaptor connected correctly? • Is the door open? |
| Playback does not function. | • Is the disc inserted correctly? • Is the disc damaged or deformed? • Has the unit been locked with the HOLD switch? • Has the unit been moved from a cold place to a hot place? Abrupt change of temperature may cause condensation to form on the lens. Keep your CD Player in a warm place until the condensation on the lens has disappeared. |
| Headphones don't work. | • Is the volume control on the unit at the minimum setting? |
| A sound or track is skipped. | • Was the unit jolted or knocked? • Is there dust, fingerprints or scratches on the disc? |
| Some of the MP3 files on a CD are not recognised. | • Check if the unreadable files have .mp3 as their extension on your PC. |
