Manual for MCD-SM60

Manual for MCD-SM60

Brand: SAMSUNG

Category: Other

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 8:13 p.m.

Main Features

  • SBS function: Produces rich, deep bass tones.
  • Random function: Allows tracks to be played in random order.
  • Album function: Enables easy browsing and searching by album name, song title, and artist.
  • ESP function: Provides high resistance to shock or vibration (up to 120 seconds for MP3, 45 seconds for CD).
  • Last Memory function: Resumes listening from where you left off.

What is MP3?

MP3 (MPEG1 Layer 3) is a global standard for audio signal compression, compressing data up to 12 times without sound quality degradation.

File Compatibility

  • Supports *.mp3 files (Mpeg1.Layer 3).
  • Supports *.mp2 files (Mpeg1.Layer2).

How many MP3 files can a CD-R or CD-RW disc record?

A 680MB disc can hold approximately 170 MP3 files (assuming 4MB per file).

Troubleshooting and error codes

Problem Check
Unit has no power.
  • Did you insert the battery with the correct polarity?
  • Is the battery exhausted?
  • Is the AC adaptor connected correctly?
  • Is the door open?
Playback does not function.
  • Is the disc inserted correctly?
  • Is the disc damaged or deformed?
  • Has the unit been locked with the HOLD switch?
  • Has the unit been moved from a cold place to a hot place? Abrupt change of temperature may cause condensation to form on the lens. Keep your CD Player in a warm place until the condensation on the lens has disappeared.
Earphones don't work.
  • Is the volume control on the main unit or on the earphones at the minimum setting?
  • Are the earphones and the main unit connected correctly?
A sound or track is skipped.
  • Was the unit jolted or knocked?
  • Are there dust, fingerprints or scratches on the disc?
Some of the MP3 files on a CD are not recognised.
  • Check if the unreadable files have .mp3 as their extension on your PC.
