Manual for DA68-03009C-06

Manual for DA68-03009C-06

Brand: SAMSUNG

Category: Refrigerator

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 7:12 p.m.

Manual Publish Date: 2016-03-24

Warranty Information

Contact SAMSUNG customer care for product inquiries and comments.

  • Freezer Control: Press the Freezer button to set the desired temperature between -15 °C and -23 °C. The display shows the current temperature after setting.
  • Power Freeze: Activates a function to speed up freezing. Indicator lights up. Energy consumption increases. Activate 20 hours before loading large amounts of food. Press again to deactivate.
  • Door Alarm: Activates an alarm if the door is left open for over 2 minutes. Press again to deactivate.
  • Temperature Alarm: Activates if the freezer compartment is too warm (e.g., after power failure). Alarm indicator lights up. Flashes "--" if compartment is too warm. Pressing the Freezer button shows the warmest temperature reached. Press Door Alarm button again to deactivate.
  • Display Off: Press Door Alarm for 3 seconds to switch the temperature display on/off.
  • Control Lock: Press Control Lock button for 3 seconds to lock all control panel buttons. Lock indicator lights up. Press again for 3 seconds to deactivate.

Troubleshooting and error codes

PROBLEM SOLUTION
The appliance is not operating at all or the temperature is too high.
  • Check if the power plug is correctly connected.
  • Is the temperature control on the front panel correctly set?
  • Does sun shine on the appliance or are there any heat sources nearby?
  • Is the back of the appliance too close to the wall?
There are unusual noises.
  • Check if the appliance is installed on a stable and even floor.
  • Is the back of the appliance too close to the wall?
  • Have any foreign objects fallen behind or under the appliance?
  • Is the noise coming from the compressor in the appliance?
  • A ticking sound may be heard inside the appliance; this is normal. This sound occurs when the various accessories contract or expand.
The front corners and sides of the appliance are warm and condensation starts to form.
  • Heat-proof pipes are installed in the front corners of the appliance to prevent condensation from forming.
  • When the surrounding temperature rises, this may not always be effective. However, this is not abnormal.
  • In very humid weather, condensation may form on the outer surface of the appliance when the moisture in the air comes into contact with the cool surface of the appliance.
You can hear a liquid bubbling in the appliance. This is the refrigerant, which cools the inside of the appliance.
There is a bad smell inside the appliance.
  • Is there any spoiled food inside of the freezer?
  • Make sure that strong smelling food (for example, fish) is wrapped so that it is airtight.
  • Clean out your freezer periodically and throw away any spoiled or suspect food.
There is a layer of frost on the appliances walls.
  • Are the air outlet vents blocked by food stored inside the freezer?
  • Space the food out as much as possible to improve ventilation.
  • Is the door fully closed?
Condensation forms on the inside wall of the appliance.
  • Food with a high water content is stored uncovered with a high humidity level or the door has been left open for a long time.
  • Store the food with a cover or in sealed containers.
