Warranty Information
One year parts and labor on the refrigerator, and five years on the sealed refrigeration system.
9-1) Digital Panel
The digital panel displays compartment temperatures and allows for temperature control via dedicated buttons. It also indicates the status of functions like Power Freeze and Power Cool.
9-2) Temperature Control FunctionUsers can set desired temperatures for the freezer (14°F to 8°F) and refrigerator (34°F to 46°F) using specific buttons. The display reflects the actual compartment temperatures.
9-3) Power Freeze and Power Cool FunctionsThese functions accelerate cooling. Power Freeze runs the compressor and freezer fan continuously for 2.5 hours. Power Cool runs the compressor and refrigerator fan until the refrigerator reaches 25°F. These functions do not alter the set temperatures.
Troubleshooting and error codes
| No | Item | LED Display | Details | Remarks |
|---|---|---|---|---|
| 1 | R-sensor | REFRIGERATOR 5 |
Connector contact failure Short-circuit |
•Suspected to be below -58°F •Suspected to be over 150°F |
| 2 | R-defroster sensor |
REFRIGERATOR d |
Connector contact failure • Short-circuit |
•Suspected to be below -58 °F •Suspected to be over 150°F |
| 3 | Outer sensor | FREEZER E5 |
Connector contact failure Short-circuit |
•Suspected to be below -58°F •Suspected to be over 150°F |
| 4 | F-sensor | FREEZER F5 |
Connector contact failure Short-circuit |
•Suspected to be below -58°F •Suspected to be over 150°F |
| 5 | F-defroster sensor |
FREEZER d5 |
Connector contact failure Short-circuit |
•Suspected to be below -58 °F •Suspected to be over 150°F |
