Using the Product

This section covers various aspects of using the LCD TV Monitor, including:

  • Plug & Play Feature: How the monitor automatically configures itself.
  • Viewing the Control Panel: Navigating and understanding the on-screen controls.
  • Remote Control: Using the provided remote for convenient operation.
  • Teletext Feature: Accessing teletext services.
  • Screen Adjustment Menu (OSD): Adjusting picture settings like brightness, contrast, etc.
  • Installing the Device Driver: How to install necessary drivers for optimal performance.
  • Standard Signal Mode Table: Information on supported resolutions and frequencies.

Installing the Software

This section guides you through installing essential software for the monitor:

  • Natural Color: Software for adjusting display colors to match printed pictures.
  • MultiScreen: Software that allows partitioning the screen into multiple sections.

Troubleshooting and error codes

PROBLEMS RELATED TO INSTALLATION (PC MODE)
The monitor screen flickers. Check if the signal cable between the computer and the monitor is securely connected and tightened.
(Refer to Connecting to a Computer)
Screen is blank and power indicator is off. Ensure that the power cord is firmly connected and the LCD monitor is on.
(Refer to Connecting to a Computer)
"Check Signal Cable" message Ensure that the signal cable is firmly connected to the PC or video sources.
(Refer to Connecting to a Computer)
"Not Optimum Mode" message Check the maximum resolution and the frequency of the video adapter.
Compare these values with the data in the Standard Signal Mode Table.
Picture rolls vertically. Check if the signal cable is securely connected.Connect it again securely.
(Refer to Connecting to a Computer)
Image is not clear. Picture is blurred. Run Frequency <Coarse> and < Fine> tuning.
Turn on again after removing all accessories(video extension cable, etc.)
Set resolution and frequency to the recommended ranges.
Picture image is unstable and vibrates. Check if the resolution and frequency set for the computer video card falls in the range supported by the monitor. If not, reset them referring to the current <Information> under the monitor menu and Standard Signal Mode Table.
Ghost images are shown in the picture. Adjust the Brightness and Contrast
(Refer to the <Brightness>, <Contrast>)
The image is too light or too dark The monitor is using its power management system
Press a key on the keyboard
Screen is blank and the power indicator light blinks every 0.5 or 1 seconds If you see the TEST GOOD message on the screen when you press the [MENU] button, check the cable connection between the monitor and the computer to ensure that the connector is properly connected.
The screen is blank and is blinking.
PROBLEMS RELATED TO AUDIO
No sound Ensure that the audio cable is firmly connected to both the audio-in port on your monitor and the audio-out port on your sound card.
(Refer to Connecting to a Computer)
The sound level is too low. Check the volume level.
If the volume is still too low after turning the control to its maximum, check the volume control on the computer sound card or software program.
PROBLEMS RELATED TO REMOTE CONTROL
The remote control buttons do not respond. Check the battery polarities (+/-).
Check if the batteries have been exhausted.
Check if the power is on.
Check if the power cord is securely connected.
Check if a special fluorescent or neon lamp is on in the vicinity
