Warranty Information
Important warranty information regarding television format viewing is provided on page 2.
- Turning the TV On and Off: Press the POWER button on the remote control or the front panel.
- Plug & Play Feature: Upon initial power-on, follow on-screen prompts to set language, video signal source, antenna input, auto program, and clock.
- Viewing Menus: Press MENU to access Input, Picture, Sound, Channel, and Setup options. Use navigation buttons to select and ENTER to confirm.
- Viewing Display: Press INFO to see current channel, signal, picture/sound modes, MTS, and time.
- Special Features (V-Chip, Closed Captions, etc.): Access via the MENU and navigate to Setup. Follow on-screen instructions for customization.
- Remote Control Setup: Use MODE and SET buttons to program the remote for VCR, Cable Box, or DVD player operation using provided codes.
Troubleshooting and error codes
| Problem | Possible Solution |
|---|---|
| Poor picture | Try another channel. Adjust the antenna. Check all wire connections. |
| Poor sound quality. | Try another channel. Adjust the antenna. |
| No picture or sound. | Try another channel. Press the TV/VIDEO button. Make sure the TV is plugged in. Check the antenna connections. |
| No color, wrong colors or tints. | Make sure the program is broadcast in color. Adjust the picture settings. If the set is moved or turned in a different direction, the power should be OFF for at least 30 minutes. |
| Picture rolls vertically. | Adjust the antenna. Check all wire connections. |
| The TV operates erratically | Unplug the TV for 30 seconds, then try operating it again. |
| The TV won't turn on. | Make sure the wall outlet is working. |
