Warranty Information
Refer to the warranty cards/registration card for details.
- Turning the TV On and Off: Press the POWER button on the remote control or the front panel.
- Plug & Play Feature: For initial setup, the TV guides you through language selection, antenna input check, channel memorization, and time setting. This feature is available in TV and DTV modes.
- Using the V-Chip: Access to channels and programs can be controlled using a password. You can enable/disable rating controls, change the password, and set up restrictions based on "TV Parental Guidelines" or "MPAA Rating".
- Using the V-Chip for Digital Channels: Parental restriction information can also be applied to DTV channels, with downloadable U.S. ratings automatically updating.
Troubleshooting and error codes
| Problem | Possible Solution |
|---|---|
| Poor picture. | Try another channel. Adjust the antenna. Check all wire connections. |
| Poor sound quality. | Try another channel. Adjust the antenna. |
| No picture or sound. | Try another channel. Press the SOURCE button. Make sure the TV is plugged in. Check the antenna connections. Make sure the MUTE button is off. |
| No color, wrong colors or tints. | Make sure the program is broadcast in color. Adjust the picture settings. |
| Picture rolls vertically. | Adjust the antenna. Check all wire connections. If you are using a VCR, check the tracking. |
| The TV operates erratically. | Unplug the TV for 30 seconds, then try operating it again. |
| Your remote control does not operate your TV. | Press the TV/DTV button to put your remote control in the "TV" mode. Make sure the remote has batteries. Check that the "+" and "-" ends of the batteries are inserted correctly. Check that the batteries are drained. |
| The TV won't turn on. | Make sure the wall outlet is working. Make sure the TV is plugged in. Make sure the remote has batteries. |
| Digital broadcasting screen problem | Please check the digital signal strength and input antenna. |
| The visual qualities of digital channels vary. | The visual qualities of digital channels may vary depending on the original production method (analog or digital). |
| Although the TV caption shows HD, the visual quality is not satisfactory. | The HD caption that appears when switching channels or when pressing the Information button on the remote control means the selected channel is a digital channel. If the broadcasting station converts an analog signal into digital and transmits the signal, the visual quality may not be perfect. |
