Shooting:
1. Turn the camera on by pressing the ON/OFF button.
2. To record a video clip, press the [REC] button. Press it again to stop.
3. To take a photo, press the [Shutter] button.
Playback:
1. Press the REC/PLAY button.
2. Use the SET button to select the desired image.
3. Press the SET button again to play.
4. Press REC/PLAY to return to recording mode.
Deleting Files:
1. Navigate to the file to delete using the SET button and press MENU.
2. Select "DELETE" and press SET.
3. Select "DELETE SINGLE" and press SET.
Copying Data:
1. Connect the camera to a computer using the USB interface cable.
2. Turn on the camera.
3. Select "COMPUTER" on the USB Connection Screen, then "CARD READER" and press SET.
4. Copy files from the camera to the computer.
Dismounting Camera:
1. Safely remove hardware by clicking the icon in the task tray.
2. Left-click on the camera drive to disconnect.
Turning Off: Press the ON/OFF button for at least 1 second.
1. Turn the camera on by pressing the ON/OFF button.
2. To record a video clip, press the [REC] button. Press it again to stop.
3. To take a photo, press the [Shutter] button.
Playback:
1. Press the REC/PLAY button.
2. Use the SET button to select the desired image.
3. Press the SET button again to play.
4. Press REC/PLAY to return to recording mode.
Deleting Files:
1. Navigate to the file to delete using the SET button and press MENU.
2. Select "DELETE" and press SET.
3. Select "DELETE SINGLE" and press SET.
Copying Data:
1. Connect the camera to a computer using the USB interface cable.
2. Turn on the camera.
3. Select "COMPUTER" on the USB Connection Screen, then "CARD READER" and press SET.
4. Copy files from the camera to the computer.
Dismounting Camera:
1. Safely remove hardware by clicking the icon in the task tray.
2. Left-click on the camera drive to disconnect.
Turning Off: Press the ON/OFF button for at least 1 second.
Troubleshooting and error codes
| Question | Answer | Action |
|---|---|---|
| The "Cannot edit video clips with unlike settings" message appears. | You have attempted to join video clips having different resolutions or frame rates. | Select video clips that have the same resolution or frame rate. |
| Why is a noise heard from a nearby TV or radio during battery recharging? | Electromagnetic waves are emitted from the charger. | Move the AC adaptor further away from the TV or radio when recharging the battery pack. |
| Why does the "Insufficient card memory" or "Insufficient internal memory" message appear? | There is no more available memory on the card or in the camera's internal memory. | Delete unnecessary files, or use a card that has more memory available. |
| Why does the "Card is protected" message appear? | The lock switch on the card is in the locked (protect) position. | Move the lock switch to the unlocked position. |
| Why can't the camera be operated? | A temporary internal circuitry problem may be the cause. | Remove the AC adaptor (optional) and the battery pack from the camera, wait a few minutes, then reinstall the battery pack and try again. |
| A problem such as inability to record or play back occurs. | The card contains files that were saved using a device other than this camera. | After saving your files to a different medium, format the card. |
| Can I use my camera abroad? | When the camera is connected to a TV, you can switch the camera's video output to NTSC or PAL. If you have questions about accessories etc., please consult with a dealer near you for advice. | |
| Why does the "System error" message appear? | A problem has occurred within the camera or card. | Check the following items: ① Remove the card and then install it again. ② Remove the battery pack and then install it again. ③ Install a different card. If "System error" still appears after performing the above steps, then take the camera to the dealer for service. |
