Brand: SANYO
Category: Digital Camera
Document Type: Manual
Language: EN
Manual for VPC-E870
Uploaded: Nov. 21, 2025, 6:48 p.m.
Warranty Information
No specific warranty period is mentioned in the provided text.
Introduction
Congratulations on your new digital camera! This manual provides step-by-step instructions for its use.System Requirements
Ensure your computer meets these requirements for optimal camera performance: OS: Windows 2000/XP/VISTA, Memory: 128MB+, HDD space: 40MB+, USB port.Package Contents
Your camera package should include: Digital camera, USB/AV 3-in-1 cable, Wrist strap, Li-ion battery, Battery charger and power cord, Camera pouch, Quick start guide, and Bundled AP-CD (Software, Driver, Manual).Main Features
Key features include 8-megapixel resolution, 15x zoom (3x optical, 5x digital), a 2.5-inch LCD, 32MB internal memory expandable with SD cards, PictBridge compatibility, slideshow playback, A/V output, and a USB port for data transfer.Troubleshooting and error codes
| Problem | Action |
|---|---|
| Camera does not turn on |
• The batteries may be exhausted. Charge or replace the batteries. • The batteries are installed incorrectly. Re-insert the batteries observing the correct polarity. |
| Camera turns off automatically | Press any button to turn on the camera. |
| LCD turns off automatically | Press any button to turn on the LCD. |
| Empty battery icon is displayed on the LCD after which camera turns off | Batteries are exhausted. Replace the batteries. |
| LCD screen displays 'Card Requires Formatting' | Memory card format not recognized. Re-format the memory card. |
| LCD screen displays 'Card is Full' | Memory card is full. Replace the memory card with a new one or delete unnecessary images from the existing card. |
| LCD screen displays 'Card is locked' | The card is protected by a protect switch mechanism. Move the switch to the unlock position. |
| Insufficient memory space to complete request | Insufficient space in memory to rotate an image. Delete unnecessary images. |
| No image displays on the TV screen | Incorrect TV-out type was selected. Set correct TV-out type to match your TV system. |
| Insufficient space on the card | Delete unnecessary images. |
