Warranty Information

Sanyo Communications products are warranted against manufacturing defects for ONE YEAR from the date of purchase.

Receiving a call: When a call comes in, the screens light up and display caller information. The incoming call LED on the handset and the SPEAKER key on the base flash. Press TALK/CALL BACK on the handset or SPEAKER on the base to answer.

Making a call: Press TALK/CALL BACK on the handset or SPEAKER on the base, then dial the number.

Volume adjustment: Use the VOLUME keys on the handset for earpiece volume and on the base for speaker volume. There are four levels.

Ringer settings: Adjust the ringer switch on the handset to ON. For the base, use the VOLUME keys to increase or decrease volume, or turn it off.

Speakerphone use: Press SPEAKER to answer or make a call. For best performance, avoid noisy areas and use in a clear space.

Intercom: Use the INT key on the handset or PAGE/INTERCOM on the base for a 2-way conversation or room monitoring.

Troubleshooting and error codes

Problem	Possible Cause / Solution
CALLER ID No Display	Is battery fully charged? Try replacing the battery. Make sure that the base is connected to a non-switched AC outlet. Disconnect the base from the plug and plug it in again. Did you order Caller ID service from your local telephone company? The display will not work unless you order Caller ID service from your phone company.
Caller ID Error Message	The phone displays this message if it detects anything other than valid Caller ID information during the silent period after the first ring. This message indicates either the presence of noises on the line, or that an invalid message has been sent from the telephone company.
TELEPHONE No dial tone	Check installation: Is the base power cord connected to a working outlet? Is the telephone line cord connected to the base unit and the wall jack? Disconnect the base from the wall jack and connect another phone to the same jack. If there is no dial tone in the second phone, the problem might be your wiring or local service. Is the handset out of range of the base? Make sure the battery is properly charged (12 continuous hours).
Did tone, but cannot dial out	Make sure the TONE/PULSE switch on the back of the base unit is set to TONE or PULSE according to your phone service. Did you reprogram directory after power outage or battery replacement?
You experience static, noise, or fading in and out	Change channels. Is handset out of range? Move closer to the base. Does the base need to be relocated? Charge battery. Make sure base is not plugged into an outlet with another household appliance.
Phone beeps	Place handset in base for a minimum of 20 seconds to reset the security code. If that does not work, charge battery for 12 continuous hours. Clean charging contacts on handset and base with a soft cloth, or an eraser. Replace battery.
Dialing from directory	Did you program the directory keys correctly? Did you follow proper dialing sequence? Make sure the TONE/PULSE switch is set to TONE or PULSE according to your phone service.
