Parts/Service for SR-361W
Uploaded: Nov. 21, 2025, 7:59 p.m.
This document is a service parts list for the SANYO SR-361W refrigerator. It details various parts with their part numbers, names, quantities, and prices. It also includes a schematic diagram illustrating the location of these parts within the appliance.
Troubleshooting and error codes
| ITEM NO. | PART NO. | PART NAME | QTY. | PRICE |
|---|---|---|---|---|
| 1 | 8332320151500 | Door Liner | 1 | |
| 2 | 8330331651800 | Gasket Assembly | 1 | |
| 3 | 8332331052900 | Mascot | 1 | |
| 4 | 8332330150201 | Handle A | 1 | |
| 5 | 833N310250902 | Foamed Door | 1 | |
| 6 | SFSHY50120SE- | Bolt #119 | 3 | |
| 7 | 8330132050700 | Hinge Top Assy | 1 | |
| 8 | 8332133050400 | Cover Hinge Top | 1 | |
| 9 | 8332232211600 | Grommet Evap. Door | 2 | |
| 10 | 8312230514697 | Evaporator Door | 1 | |
| 11 | 8334233C50101 | Thermostat | 1 | |
| 12 | S1440100001000 | Tapping Screw 023 | 31 | |
| 13 | 8332612050100 | Knob Thermo | 1 | |
| 14 | 8330132050800 | Hinge Bottom | 1 | |
| 16 | 8312430970000 | Bolt, 050 | 1 | |
| 17 | 8332111050000 | Leg | 2 | |
| 18 | 4243C24500 | Power Cord | 1 | |
| 19 | 8312532784100 | Cord Clamp | 1 | |
| 20 | 8332530850100 | Cover, Wire Splicer | 1 | |
| 21 | S0440080001T00 | Machine Screw | 1 | |
| 22 | SFSHY50120SE- | Bolt | 4 | |
| 23 | 8332120150200 | Plate Cabinet Base | 1 | |
| 24 | OBC2892600100 | Clip, Relay Cover | 1 | |
| 25 | OBC2533800100 | Cover, Relay | 1 | |
| 26 | 8334204C50500 | PTC Thermistor | 1 | |
| 27 | 4BC4S20000500 | Overload Protector | 1 | |
| 28 | 3903000516 | Clamp | 1 | |
| 29 | 8330410251200 | Condenser | 1 | |
| 30 | 8312433184800 | Plate Support Condenser | 3 | |
| 31 | 8310410191073 | Evaporator Assembly | 1 | |
| 33 | 8332320250911 | D-Shelf Trim | 2 | |
| 34 | 8332322150100 | D-Shelf Bush L | 1 | |
| 35 | 8332322150200 | D-Shelf Bush R | 1 | |
| 36 | S0440080001T00 | Machine Screw 026 | 2 | |
| 37 | 8332432750200 | Clamp Thermo Bulb | 1 | |
| 38 | 8330420250700 | Dryer 8gr | 1 | |
| 39 | 8312430970000 | Bolt 050 | 4 | |
| 40 | 8312430683100 | Grommet Comp.Mtg | 3 | |
| 41 | OBC8035715210 | Compressor | 1 | |
| 42 | 8312221482371 | Ice Cube Tray | 2 | |
| 43 | 8332220250700 | Drip Tray | 1 | |
| 44 | 8312220592171 | Shelf, Upper | 2 | |
| 45 | 8312220592271 | Shelf, Lower | 1 | |
| 46 | 8332320350300 | Panel Bar | 1 | |
| 47 | 8312322180100 | Door Shelf Bushing | 2 | |
| 48 | 8319232500100 | Evap. Bracket w/pin | 1 | |
| 8002530811400 | Nylon Cable | 1 | ||
| 8332330150301 | Handle B | 1 | ||
| 8332532650200 | Clip Wire | 1 | ||
| S31050160001GT | 027 Bolt | 3 | ||
| 8336451950211 | Warranty Card | 1 | ||
| 8336460140000 | Owners Manual | 1 | ||
| 8336460640100 | FTC Label | 1 |
