Projector Operation Check

Begin by checking the POWER and STATUS indicators before disassembling the projector.

Power LED Status:

  • Orange ON: Standby/Idle
  • Green ON: Power ON
  • Orange Blink: Cooling
  • Green Blink: Power up sequence
  • Blank: AC Off

Status LED Errors (Flashing Red):

  • 1 blink: Cover Error
  • 2 blinks: Temperature Error
  • 3 blinks: Power Error
  • 4 blinks: Fan Error

Lamp LED Errors (Flashing Red):

  • RED BLINK: End of Lamp Life
  • 1 blink: No Lamp
  • 6 blinks: Lamp Error
  • RED ON: Lamp Life Over

If no errors are indicated by the LEDs, proceed to check main board voltages and signals.

Troubleshooting and error codes

Projector StatusLED ConditionLED SequenceProjector Condition
Power LEDBLANKOFFAC Off
Power LEDORANGE BLINK0.5sON > 0.5sOFFCooling
Power LEDGREEN BLINK0.5sON > 0.5sOFFPower up sequence
Power LEDORANGE ONONStandby / Idle
Power LEDGREEN ONONPower ON
Status LEDBLANKOFFNormal Condition
Status LEDRED 1 time BLINK (repeatlly)0.5sON > 2.5sOFFCover ERROR
Status LEDRED 2 times BLINK (repeatlly)(0.5sON > 0.5sOFF) * 2 > 2.0sOFFTemperature ERROR
Status LEDRED 3 times BLINK (repeatlly)(0.5sON > 0.5sOFF) * 3 > 2.0sOFFPower ERROR
Status LEDRED 4 times BLINK (repeatlly)(0.5sON > 0.5sOFF) * 4 > 2.0sOFFFAN ERROR
Status LEDORANGE light upONKeylocked (when push key)
Status LEDGREEN ONONIdle
Lamp LEDBLANKOFFLamp Off
Lamp LEDRED BLINK0.5sON > 0.5sOFFEnd of the Lamp life
Lamp LEDRED 1 time BLINK (repeatlly)0.5sON > 2.5sOFFNO LAMP
Lamp LEDRED 6 times BLINK (repeatlly)(0.5sON > 0.5sOFF) * 6 > 2.0sOFFLamp ERROR
Lamp LEDORANGE BLINK0.5sON > 0.5sOFFCooling Lamp
Lamp LEDGREEN BLINK0.5sON > 0.5sOFFRe-Light up sequence
Lamp LEDRED ONONLamp life Over (Cannot lamp on)
Lamp LEDORANGE ONONEco mode
Lamp LEDGREEN ONONNormal mode
