Manual for MD-MT280E

Manual for MD-MT280E

Brand: SHARP

Category: Audio

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 9:25 p.m.

Warranty Information

The guarantee covers domestic use for one year against faulty workmanship or materials.

Basic Operation: Recording

  1. Cancel the hold mode.
  2. Press the REC button.
  3. Begin playback on the connected stereo system.
  4. Adjust the recording level using the REC LEVEL buttons.
  5. Press the MENU/ENTER button, select "REC MODE", and choose the desired recording mode (SP, LP2, LP4, MONO).
  6. Press the RECORD button to start recording.
  7. Begin playback on the stereo system to record the output.
  8. To stop recording, press the :OFF/HOLD button.

Basic Operation: Playback

  1. Insert earphones into the remote control unit.
  2. Plug the remote control into the unit.
  3. Insert a MiniDisc.
  4. Press the Play button (►II). Playback starts automatically.
  5. Use VOL +/- buttons to adjust volume.

Advanced Playback

  • Fast Forward/Reverse: Hold down the ◄◄ or ►►► button.
  • Locate Track: Press ◄◄ or ►►► when stopped to locate previous/next track. Press during playback to restart current track or go to next.
  • Playback Modes: Select RANDOM, RANDOM REP, ALL REPEAT, or 1Tr REPEAT via the MENU/ENTER button.

Advanced Recording

  • Long-play recording (LP2, LP4) and Monaural recording (MONO) are possible using the MENU/ENTER button to select "REC MODE".

Editing a Recorded MiniDisc

  • Tracks can be moved using the MOVE function within the EDIT menu.

Listening Through Another System

  • Connect to a stereo system's LINE INPUT or AUDIO OUT sockets.
  • Connect to a car stereo using optional adapters.

Maintenance

  • Clean the unit with a soft cloth. Clean plugs and sockets to prevent noise.
  • Moisture condensation may occur; remove MiniDisc and leave unit for an hour to dry.

Troubleshooting and error codes

SYMPTOM LIMITATIONS
"DISC FULL" or "TOC FULL" appears even though the MiniDisc still has re-cording time left. More than 255 tracks (maximum) cannot be recorded regardless of the recording time. If the MiniDisc is recorded or edited repeatedly or if it has scratches (recording skips scratched parts), you may not be able to record the maximum tracks above.
The remaining recording time does not increase even though you erased tracks. The unit does not count non-recorded portions that last 12 or fewer seconds to display the remaining recording time. The time may not increase even if you erase short tracks.
The total of the recorded time and the remaining time does not match the max-imum recordable time. One cluster (approximately 2 seconds) is the minimum unit for re-cording. For example, a 3-second track uses 2 clusters (approximate-ly 4 seconds). Therefore, the actual recordable time may be shorter than the displayed time.
Combine function does not work. A MiniDisc on which recording and editing are repeated may not al-low the combine function.
Sound skips in fast reverse/forward. If one track is divided and recorded in separate places on a repeat-edly recorded or edited MiniDisc, sound may skip.
A track number is created in the middle of a track. A track number may be created if there are scratches or dust on the MiniDisc.
