Brand: SHARP
Category: Home Appliances
Document Type: Parts/Service
Language: EN
Parts/Service for DV-NC65H/S DV-NC70H
Uploaded: Nov. 21, 2025, 7:59 p.m.
Warranty Information
No specific warranty information found in the provided pages.
Common Features
- A DVD, CD player and VCR all in one.
- Simultaneous VCR recording and DVD playback.
VCR Features
- VHS Hi-Fi Stereo Sound/Double-Azimuth 4-Heads
- 1 minute Rewind (E-180)
- S-VHS Simple Playback
- HQ (High Quality) Circuitry
- Simple Recording Timer
- Sharp Super Picture
DVD Features
- Plays DVD, CD (Digital Audio) discs as well as CD-R/CD-RW discs recorded in MP3 file format
- 3D Virtual Surround provides high-quality surround sound
- Digital Gamma correction
- Dolby Digital*1/DTS*2, MPEG Audio digital out capability
- High-quality digital images
- High-quality digital sound
Troubleshooting and error codes
| Parts | Maintained | 500 hrs. | 1000 hrs. | 1500 hrs. | 2000 hrs. | Possible symptom encountered | Remarks |
|---|---|---|---|---|---|---|---|
| Guide roller ass'y | Abnormal rotation or significant vibration requires replacement. | ||||||
| Sup guide shaft | Lateral noises Head occasionally blocked | Clean tape contact part with the specified cleaning liquid. | |||||
| Reverse guide | Clean tape contact part with the specified cleaning liquid. | ||||||
| Slant pole on pole base | |||||||
| Full erase head | Colour and beating | ||||||
| A/C head | Small sound or sound distortion | ||||||
| Upper and lower drum ass'y | Poor S/N ratio, no colour | Clean tape contact area with the specified cleaning liquid. | |||||
| Capstan D.D. motor | No tape running, uneven color | ||||||
| Pinch roller | No tape running, tape slack | Clean rubber and rubber contact area with the specified cleaning liquid. | |||||
| Reel belt | No tape running, tape slack, no fast forward/ rewind motion | ||||||
| Tension band ass'y | Screen swaying | ||||||
| Loading motor | Cassette not loaded or unloaded | ||||||
| Idler ass'y | No tape running, tape slack | ||||||
| Limiter pulley | |||||||
| Supply/take-up main brake levers | Tape slack | ||||||
| AHC (Automatic head cleaner) | Replace the roller of the cleaner when it wears down. Just change the AHC roller assembly for new one. |
