Manual for KD-HD9S7GW-W

Manual for KD-HD9S7GW-W

Brand: SHARP

Category: Home Appliances

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 6:33 p.m.

Warranty Information

The service life of your tumble dryer is 10 years, with spare parts availability.

  • Ensure laundry items have a dryer-safe label.
  • Sort laundry by fabric type and color.
  • Remove all objects from pockets (lighters, matches).
  • Tie belts and laces, close zippers and buttons.
  • Select the appropriate drying programme based on fabric type and desired dryness level.
  • Press the Start/Pause button to begin the cycle.
  • Empty the water tank and clean lint filters after each use.
  • Clean the heat exchanger periodically as indicated.

Troubleshooting and error codes

PROBLEM REASON SOLUTION
The drying process takes a long time. The surface of the lint filter might be clogged. Wash the filter with lukewarm water.
The heat exchanger might be clogged. Clean the heat exchanger
The ventilation grills in front of the machine might be closed. Open the doors/windows to prevent the room temperature from rising too much.
There might be a layer of limescale on the humidity sensor. Clean the humidity sensor.
The dryer might be overloaded with laundry. Do not overload the dryer.
The laundry might be insufficiently spun. Select a higher spin speed on your washing machine.
The laundry that comes out hot at the end of the drying process generally feels more humid. The programme used might not be suitable for the type of laundry. Check the care labels on the laundry items, select a suitable programme for the type of laundry and additionally, use the time programmes.
Laundry comes out damp at the end of the drying process. The surface of the lint filter might be clogged. Wash the filter with lukewarm water.
The heat exchanger might be clogged. Clean the heat exchanger
The dryer might be overloaded with laundry. Do not overload the dryer.
The laundry might be insufficiently spun. Select a higher spin speed on your washing machine.
The dryer cannot be opened or the programme cannot be started. The dryer does not get activated when adjusted. The dryer might not be plugged in. Make sure that the plug is fitted in the socket.
The loading door might be open. Make sure that the loading door is properly closed.
You might not have set a programme or pressed the Start/Pause key. Make sure that the programme has been set and the dryer is not in the Standby (Pause) mode.
Child lock might be active. Deactivate the child lock.
The programme has been interrupted for no reason. The loading door might not be closed properly. Make sure that the loading door is properly closed.
There might have been a power failure. Press the Start/Pause key to start the programme.
The water tank might be full. Empty the water tank.
Clothes have shrunk, felted or deteriorated. The programme used might not be suitable for the type of laundry. Check the care labels on the laundry items, select a suitable programme for the type of laundry.
Water leaking from the loading door. There might be lint accumulated on the inner surfaces of the loading door and on the surfaces of the gasket of the loading door. Clean the inner surfaces of the loading door and the surfaces of the gasket of the loading door.
The loading door might not be closed properly. Push the loading door until you hear the closing sound.
The loading door opens on its own. The water tank might be full. Empty the water tank.
The water tank warning symbol is on/flashing. The water discharge hose might be bent. If the product is connected directly to the water outlet, check the water discharge hose.
The filter cleaning warning symbol is on. The lint filter might be unclean. Clean the filter.
The filter seat might be clogged by lint. Clean the filter seat.
There might be a layer that causes obstruction on the surface of the lint filter. Wash the filter with lukewarm water.
The heat exchanger cleaning warning symbol is on. The heat exchanger might be unclean. Clean the heat exchanger.
