Brand: SHARP
Category: Home Appliances
Document Type: Manual
Language: EN
Manual for KD-HHH0S7EW2-FR
Uploaded: Nov. 21, 2025, 9:22 p.m.
Warranty Information
The manufacturer cannot be held responsible for damages resulting from un-authorised repairs or incorrect use.
Control Panel: Use the "Programme Selection Knob" to choose a drying program. The electronic display shows program status and functions.
Programme Selection: Choose from various programs like Cotton Extra Dry, Cotton Cupboard Dry, Synthetics Iron Dry, Delicate, Time Drying, Baby Care, Duvet, Sport, Mix, Wool Refresh, Refresh, Express 34', and Shirts 20'. Each program has specific load capacities, spin speeds, remaining humidity levels, and durations.
Auxiliary Functions: Options include Drying Level adjustment, Anti-Crease, Delay Start, Buzzer Cancel, Time Drying, and Child Lock.
Starting a Programme: Press the Start/Pause button. The LED indicates the program has started.
Programme End: Warnings for water tank, filter cleaning, and heat exchanger cleaning will activate. Remove laundry promptly. Use the 1-hour Anti Crease phase if needed.
Cleaning: Regularly clean lint filters after each use. Empty the water tank after each use. Clean the heat exchanger monthly or every 30 drying processes. Clean the humidity sensors four times a year. Clean the inner surface of the loading door after each drying process.
Programme Selection: Choose from various programs like Cotton Extra Dry, Cotton Cupboard Dry, Synthetics Iron Dry, Delicate, Time Drying, Baby Care, Duvet, Sport, Mix, Wool Refresh, Refresh, Express 34', and Shirts 20'. Each program has specific load capacities, spin speeds, remaining humidity levels, and durations.
Auxiliary Functions: Options include Drying Level adjustment, Anti-Crease, Delay Start, Buzzer Cancel, Time Drying, and Child Lock.
Starting a Programme: Press the Start/Pause button. The LED indicates the program has started.
Programme End: Warnings for water tank, filter cleaning, and heat exchanger cleaning will activate. Remove laundry promptly. Use the 1-hour Anti Crease phase if needed.
Cleaning: Regularly clean lint filters after each use. Empty the water tank after each use. Clean the heat exchanger monthly or every 30 drying processes. Clean the humidity sensors four times a year. Clean the inner surface of the loading door after each drying process.
Troubleshooting and error codes
| PROBLEM | REASON | SOLUTION |
|---|---|---|
| The drying process takes a long time. | The surface of the lint filter might be clogged. | Wash the filter with lukewarm water. |
| The heat exchanger might be clogged. | Clean the heat exchanger | |
| The ventilation grills in front of the machine might be closed. | Open the doors/windows to prevent the room temperature from rising too much. | |
| There might be a layer of limescale on the humidity sensor. | Clean the humidity sensor. | |
| Laundry comes out damp at the end of the drying process. | The dryer might be overloaded with laundry. | Do not overload the dryer. |
| The laundry might be insufficiently spun. | Select a higher spin speed on your washing machine. | |
| The laundry that comes out hot at the end of the drying process generally feels more humid. | Check the care labels on the laundry items, select a suitable programme for the type of laundry and additionally, use the time programmes. | |
| The dryer cannot be opened or the programme cannot be started. The dryer does not get activated when adjusted. | The surface of the lint filter might be clogged. | Wash the filter with lukewarm water. |
| The heat exchanger might be clogged. | Clean the heat exchanger | |
| The dryer might be overloaded with laundry. | Do not overload the dryer. | |
| The laundry might be insufficiently spun. | Select a higher spin speed on your washing machine. | |
| The dryer might not be plugged in. | Make sure that the plug is fitted in the socket. | |
| The programme has been interrupted for no reason. | The loading door might be open. | Make sure that the loading door is properly closed. |
| You might not have set a programme or pressed the Start/Pause key. | Make sure that the programme has been set and the dryer is not in the Standby (Pause) mode. | |
| Child lock might be active. | Deactivate the child lock. | |
| The loading door might not be closed properly. | Make sure that the loading door is properly closed. | |
| There might have been a power failure. | Press the Start/Pause key to start the programme. | |
| The water tank might be full. | Empty the water tank. | |
| Clothes have shrunk, felted or deteriorated. | The programme used might not be suitable for the type of laundry. | Check the care labels on the laundry items, select a suitable programme for the type of laundry. |
| Water leaking from the loading door. | There might be lint accumulated on the inner surfaces of the loading door and on the surfaces of the gasket of the loading door. | Clean the inner surfaces of the loading door and the surfaces of the gasket of the loading door. |
| The loading door opens on its own. | The loading door might not be closed properly. | Push the loading door until you hear the closing sound. |
| The water tank warning symbol is on/flashing. | The water tank might be full. | Empty the water tank. |
| The water discharge hose might be bent. | If the product is connected directly to the water outlet, check the water discharge hose. | |
| The heat exchanger cleaning warning symbol is on. | The heat exchanger might be unclean. | Clean the heat exchanger. |
| The filter and heat exchanger cleaning warning symbol are flashing. | The filter cleaning warning symbol is on. | The lint filter might be unclean. |
| The filter seat might be clogged by lint. | Clean the filter seat. | |
| There might be a layer that causes obstruction on the surface of the lint filter. | Wash the filter with lukewarm water. | |
| The program can not be started and the filter warning led is blinking. | The filter seat might be clogged by lint. | Clean the filter seat. |
| There might be a layer that causes obstruction on the surface of the lint filter. | Wash the filter with lukewarm water. | |
| The heat exchanger might be clogged. | Clean the heat exchanger. | |
| The filter may not be placed. | Replace the filter. | |
| The filter warning led is blinking even though the filter is placed. | Call technical service. |
