Brand: SHARP
Category: Home Appliances
Document Type: Manual
Language: EN
Manual for KD-HHH9S8GW3-EE
Uploaded: Nov. 21, 2025, 6:42 p.m.
Warranty Information
The manufacturer will not accept responsibility for damages resulting from incorrect use or transport.
The user manual provides comprehensive instructions for operating the SHARP KD-HHH9S8GW3-EE Tumble Dryer. It covers essential safety precautions, installation guidelines, and detailed steps for preparing laundry, selecting programs, and using the control panel. Key features include program selection, electronic indicators, auxiliary functions like drying level, anti-crease, and delay start. The manual also outlines cleaning and maintenance procedures for filters, water tank, and heat exchanger, along with troubleshooting tips for common issues and automatic fault warnings. Energy efficiency information and technical specifications are also provided.
Troubleshooting and error codes
| PROBLEM | CAUSE | SOLUTION |
|---|---|---|
| Drying process takes too long. | The surface of the lint filter may be clogged. | Wash the filter with lukewarm water. |
| The heat exchanger may be clogged. | Clean the heat exchanger. | |
| Ventilation grilles on the front of the appliance may be closed. | Open doors/windows to prevent excessive room temperature. | |
| A layer of limescale may be deposited on the humidity sensor. | Clean the humidity sensor. | |
| The dryer is unbalanced and possibly overloaded with laundry. | Do not overload the dryer. | |
| Laundry is unbalanced and possibly not wrung out enough. | Select a higher spin speed on the washing machine. | |
| Laundry remains damp after drying. | Hot laundry removed from the dryer after drying usually feels slightly damp. | When the laundry is selected after drying from the dryer, it usually feels slightly damp. |
| The selected program may not be suitable for this type of laundry. | Check the labels on the individual pieces of laundry, select a suitable program for the given type of laundry, and use time programs additionally. | |
| The dryer cannot be opened, or the program cannot be started. The dryer is unbalanced and, when balanced and set. | The surface of the lint filter may be clogged. | Wash the filter with lukewarm water. |
| The heat exchanger may be clogged. | Clean the heat exchanger. | |
| The dryer is unbalanced and possibly overloaded with laundry. | Do not overload the dryer. | |
| Laundry is unbalanced and possibly not wrung out enough. | Select a higher spin speed on the washing machine. | |
| The dryer may not be balanced and connected to the mains. | Check if the dryer and plug are properly connected to the socket. | |
| The filling door may have remained ajar. | Ensure the filling door is properly closed. | |
| You may not have set the program, or you may not have pressed the Start/Pause button. | Make sure the program is selected and the dryer is not in standby or paused mode. | |
| Child lock may be activated. | Deactivate the child lock. | |
| Program interrupted without reason. | The filling door may not be properly closed. | Ensure the filling door is properly closed. |
| Possible power failure. | Press Start/Pause button to start the program. | |
| The water tank is unbalanced and possibly full. | Empty the water tank. | |
| Clothes have shrunk, are tangled, or in poor condition. | The selected program may not be suitable for this type of laundry. | Check the labels on the items, select the appropriate program for the type of laundry, and use additional time programs. |
| Water leaking from the filling door. | Lint may have accumulated on the inner side of the filling door and on the sealing surface of the filling door. | Clean the inner side of the filling door and the sealing surfaces of the filling door. |
| Filling door opens by itself. | The filling door may not be properly closed. | Push the filling door until you hear a closing sound. |
| The water tank is unbalanced and possibly full. | Empty the water tank. | |
| Water tank symbol is lit/flashing. | The water drain hose may be bent. | If the product is connected directly to the pipe, check the water drain hose. |
| Filter cleaning symbol is lit. | The lint filter may be clogged. | Clean the filter. |
| The filter bed may be clogged with lint. | Clean the lint filter bed. | |
| A layer may have formed, obstructing the lint filter. | Wash the filter with lukewarm water. | |
| Heat exchanger cleaning warning symbol is lit. | The heat exchanger is possibly dirty. | Clean the heat exchanger. |
