Warranty Information
The manufacturer cannot be held responsible for damages resulting from un-authorised repairs.
Using the Tumble Dryer
Control Panel: Familiarize yourself with the Programme Selection Knob and the Electronic Indicator.
Programme Selection: Turn the knob to choose your desired drying programme (e.g., Cotton Extra Dry, Synthetics Cupboard Dry, Delicate). Refer to the Programme Selection and Consumption Table for details on each program, including load capacity, washing machine spin speed, desired humidity, and duration.
Auxiliary Functions: Enhance your drying cycle with options like Delicate, Drying Level adjustment, Anti-Crease, Delay Start, Time Drying, Buzzer Cancel, and Child Lock.
Starting the Programme: Press the Start/Pause button to begin the cycle. The Start/Pause LED will indicate the program has started.
During the Programme: Avoid opening the door unnecessarily. If you must open it, do so for a short time and then press Start/Pause to resume.
Programme End: Once complete, remove laundry promptly. Clean the lint filter and empty the water tank after each use.
Drum Light: The LED drum light illuminates automatically when the door is opened and turns off after a while.
Troubleshooting and error codes
| PROBLEM | REASON | SOLUTION |
|---|---|---|
| The drying process takes a long time. | The surface of the lint filter might be clogged. | Wash the filter with lukewarm water. |
| The condenser might be clogged. | Clean the condenser. | |
| The ventilation grills in front of the machine might be closed. | Open the doors/windows to prevent the room temperature from rising too much. | |
| There might be a layer of limescale on the humidity sensor. | Clean the humidity sensor. | |
| The dryer might be overloaded with laundry. | Do not overload the dryer. | |
| Laundry comes out damp at the end of the drying process. | The laundry might be insufficiently spun. | Select a higher spin speed on your washing machine. |
| The laundry that comes out hot at the end of the drying process generally feels more humid. | N/A | |
| The programme used might not be suitable for the type of laundry. | Check the care labels on the laundry items, select a suitable programme for the type of laundry and additionally, use the time programmes. | |
| The surface of the lint filter might be clogged. | Wash the filter with lukewarm water. | |
| The condenser might be clogged. | Clean the condenser. | |
| The dryer cannot be opened or the programme cannot be started. The dryer does not get activated when adjusted. | The dryer might not be plugged in. | Make sure that the plug is fitted in the socket. |
| The loading door might be open. | Make sure that the loading door is properly closed. | |
| You might not have set a programme or pressed the Start/Pause key. | Make sure that the programme has been set and the dryer is not in the Standby (Pause) mode. | |
| Child lock might be active. | Deactivate the child lock. | |
| The loading door might not be closed properly. | Make sure that the loading door is properly closed. | |
| The programme has been interrupted for no reason. | There might have been a power failure. | Press the Start/Pause key to start the programme. |
| The water tank might be full. | Empty the water tank. | |
| The programme used might not be suitable for the type of laundry. | Check the care labels on the laundry items, select a suitable programme for the type of laundry. | |
| The condenser might be unclean. | Clean the condenser. | |
| Clothes have shrunk, felted or deteriorated. | The programme used might not be suitable for the type of laundry. | Check the care labels on the laundry items, select a suitable programme for the type of laundry. |
| Water leaking from the loading door. | There might be lint accumulated on the inner surfaces of the loading door and on the surfaces of the gasket of the loading door. | Clean the inner surfaces of the loading door and the surfaces of the gasket of the loading door. |
| The loading door opens on its own. | The loading door might not be closed properly. | Push the loading door until you hear the closing sound. |
| The water tank warning symbol is on/flashing. | The water tank might be full. | Empty the water tank. |
| The water discharge hose might be bent. | If the product is connected directly to the water outlet, check the water discharge hose. | |
| The condenser cleaning warning symbol is on. | The condenser might be unclean. | Clean the condenser. |
| The filter cleaning warning symbol is on. | The lint filter might be unclean. | Clean the filter. |
| The filter seat might be clogged by lint. | Clean the filter seat. | |
| There might be a layer that causes obstruction on the surface of the lint filter. | Wash the filter with lukewarm water. | |
| The program can not be started and the filter warning led is blinking | There might be a layer that causes obstruction on the surface of the lint filter. | Wash the filter with lukewarm water. |
| The program can not be started and both condenser and filter warning leds are blinking | The condenser and filter may not be placed. | Replace the filter and condenser. |
