Warranty Information
The manufacturer cannot be held responsible for damages resulting from un-authorised repairs or incorrect use.
The tumble dryer is designed for household and indoor use. Before use, prepare laundry by sorting and ensuring it's suitable for drying according to care labels. Prepare the dryer by ensuring it's installed on a stable surface with proper electrical connection and ventilation. Load the dryer respecting the maximum capacity. Select the appropriate drying programme using the Programme Selection Knob and any desired Auxiliary Functions. Press the Start/Pause button to begin the cycle. During operation, avoid opening the door unless necessary. Upon completion, remove laundry promptly. Regular cleaning of the lint filter, water tank, and condenser is essential for optimal performance and longevity.
Troubleshooting and error codes
| PROBLEM | REASON | SOLUTION |
|---|---|---|
| The drying process takes a long time. | The surface of the lint filter might be clogged. | Wash the filter with lukewarm water. |
| The condenser might be clogged. | Clean the condenser. | |
| The ventilation grills in front of the machine might be closed. | Open the doors/windows to prevent the room temperature from rising too much. | |
| There might be a layer of limescale on the humidity sensor. | Clean the humidity sensor. | |
| The dryer might be overloaded with laundry. | Do not overload the dryer. | |
| The laundry might be insufficiently spun. | Select a higher spin speed on your washing machine. | |
| Laundry comes out damp at the end of the drying process. | The laundry that comes out hot at the end of the drying process generally feels more humid. | |
| The programme used might not be suitable for the type of laundry. | Check the care labels on the laundry items, select a suitable programme for the type of laundry and additionally, use the time programmes. | |
| The surface of the lint filter might be clogged. | Wash the filter with lukewarm water. | |
| The condenser might be clogged. | Clean the condenser. | |
| The dryer might be overloaded with laundry. | Do not overload the dryer. | |
| The laundry might be insufficiently spun. | Select a higher spin speed on your washing machine. | |
| The dryer cannot be opened or the programme cannot be started. The dryer does not get activated when adjusted. | The dryer might not be plugged in. | Make sure that the plug is fitted in the socket. |
| The loading door might be open. | Make sure that the loading door is properly closed. | |
| You might not have set a programme or pressed the Start/Pause key. | Make sure that the programme has been set and the dryer is not in the Standby (Pause) mode. | |
| Child lock might be active. | Deactivate the child lock. | |
| The programme has been interrupted for no reason. | The loading door might not be closed properly. | Make sure that the loading door is properly closed. |
| There might have been a power failure. | Press the Start/Pause key to start the programme. | |
| The water tank might be full. | Empty the water tank. | |
| Clothes have shrunk, felted or deteriorated. | The programme used might not be suitable for the type of laundry. | Check the care labels on the laundry items, select a suitable programme for the type of laundry. |
