Warranty Information

The manufacturer cannot be held responsible for damages resulting from un-authorised repairs.

Drying Laundry:
  1. Sort laundry by fabric type and care label instructions.
  2. Ensure pockets are empty and fasteners are secured.
  3. Select the appropriate drying programme using the control panel.
  4. Press the Start/Pause button to begin the cycle.
  5. Remove laundry promptly at the end of the cycle.
Cleaning and Care:
  1. Clean lint filters after each use.
  2. Empty the water tank after each drying process.
  3. Clean the heat exchanger regularly (monthly or after 30 uses).
  4. Wipe the humidity sensors with a soft cloth.
  5. Clean the inner surface of the loading door after each drying process.
Troubleshooting:
  • Refer to the troubleshooting table for common issues like long drying times, damp laundry, or failure to start.
  • Ensure filters are clean, the dryer is not overloaded, and the door is properly closed.
  • Check for error codes (E03-E08) for specific malfunctions.

Troubleshooting and error codes

PROBLEM REASON SOLUTION
The drying process takes a long time. The surface of the lint filter might be clogged. Wash the filter with lukewarm water.
The heat exchanger might be clogged. Clean the heat exchanger
The ventilation grills in front of the machine might be closed. Open the doors/windows to prevent the room temperature from rising too much.
There might be a layer of limescale on the humidity sensor. Clean the humidity sensor.
The dryer might be overloaded with laundry. Do not overload the dryer.
The laundry might be insufficiently spun. Select a higher spin speed on your washing machine.
The laundry that comes out hot at the end of the drying process generally feels more humid. Check the care labels on the laundry items, select a suitable programme for the type of laundry and additionally, use the time programmes.
Laundry comes out damp at the end of the drying process. The surface of the lint filter might be clogged. Wash the filter with lukewarm water.
The heat exchanger might be clogged. Clean the heat exchanger
The dryer might be overloaded with laundry. Do not overload the dryer.
The laundry might be insufficiently spun. Select a higher spin speed on your washing machine.
The dryer might not be plugged in. Make sure that the plug is fitted in the socket.
The loading door might be open. Make sure that the loading door is properly closed.
The dryer cannot be opened or the programme cannot be started. The dryer does not get activated when adjusted. You might not have set a programme or pressed the Start/Pause key. Make sure that the programme has been set and the dryer is not in the Standby (Pause) mode.
Child lock might be active. Deactivate the child lock.
The loading door might not be closed properly. Make sure that the loading door is properly closed.
There might have been a power failure. Press the Start/Pause key to start the programme.
The programme has been interrupted for no reason. The water tank might be full. Empty the water tank.
Clothes have shrunk, felted or deteriorated. The programme used might not be suitable for the type of laundry. Check the care labels on the laundry items, select a suitable programme for the type of laundry.
There might be lint accumulated on the inner surfaces of the loading door and on the surfaces of the gasket of the loading door. Clean the inner surfaces of the loading door and the surfaces of the gasket of the loading door.
The loading door might not be closed properly. Push the loading door until you hear the closing sound.
Water leaking from the loading door. The water tank might be full. Empty the water tank.
The loading door opens on its own. The water discharge hose might be bent. If the product is connected directly to the water outlet, check the water discharge hose.
The water tank warning symbol is on/flashing. The heat exchanger might be unclean. Clean the heat exchanger.
The heat exchanger cleaning warning symbol is on. The lint filter might be unclean. Clean the filter.
The filter cleaning warning symbol is on. The filter seat might be clogged by lint. Clean the filter seat.
The filter and heat exchanger cleaning warning symbol are flashing. There might be a layer that causes obstruction on the surface of the lint filter. Wash the filter with lukewarm water.
The filter seat might be clogged by lint. Clean the filter seat.
The program can not be started and the filter warning led is blinking. There might be a layer that causes obstruction on the surface of the lint filter. Wash the filter with lukewarm water.
The heat exchanger might be clogged. Clean the heat exchanger.
The filter may not be placed. Replace the filter.
The filter warning led is blinking even though the filter is placed. Call technical service.
