Warranty Information

Failure to follow safety instructions will void the warranty.

Getting Started:

  • Preparation: Sort laundry by fabric type and dryness level. Remove items from pockets and secure fasteners.
  • Loading: Do not overload the dryer. Ensure items are suitable for drying.
  • Programme Selection: Use the Programme Selection Knob to choose a programme. Consult the "Programme Selection and Consumption Table" for load capacities and drying times.
  • Starting: Press the Start/Pause button. The Start/Pause LED will indicate the programme has begun.
  • During Drying: Avoid opening the door unnecessarily.
  • After Drying: Remove laundry promptly to prevent creasing.
  • Maintenance: Regularly clean lint filters, empty the water tank, and clean the heat exchanger and humidity sensor as instructed.

Key Features:

  • Multiple drying programmes for different fabric types.
  • Time drying option for specific needs.
  • Delay Start and Anti-Crease functions.
  • Child Lock feature for safety.

Troubleshooting and error codes

PROBLEM REASON SOLUTION
The drying process takes a long time. The surface of the lint filter might be clogged. Wash the filter with lukewarm water.
The heat exchanger might be clogged. Clean the heat exchanger
The ventilation grills in front of the machine might be closed. Open the doors/windows to prevent the room temperature from rising too much.
There might be a layer of limescale on the humidity sensor. Clean the humidity sensor.
The dryer might be overloaded with laundry. Do not overload the dryer.
Laundry comes out damp at the end of the drying process. The laundry might be insufficiently spun. Select a higher spin speed on your washing machine.
The programme used might not be suitable for the type of laundry. Check the care labels on the laundry items, select a suitable programme for the type of laundry and additionally, use the time programmes.
The dryer cannot be opened or the programme cannot be started. The dryer does not get activated when adjusted. The dryer might not be plugged in. Make sure that the plug is fitted in the socket.
The loading door might be open. Make sure that the loading door is properly closed.
You might not have set a programme or pressed the Start/Pause key. Make sure that the programme has been set and the dryer is not in the Standby (Pause) mode.
Child lock might be active. Deactivate the child lock.
The programme has been interrupted for no reason. The loading door might not be closed properly. Make sure that the loading door is properly closed.
There might have been a power failure. Press the Start/Pause key to start the programme.
The water tank might be full. Empty the water tank.
Clothes have shrunk, felted or deteriorated. The programme used might not be suitable for the type of laundry. Check the care labels on the laundry items, select a suitable programme for the type of laundry.
Water leaking from the loading door. There might be lint accumulated on the inner surfaces of the loading door and on the surfaces of the gasket of the loading door. Clean the inner surfaces of the loading door and the surfaces of the gasket of the loading door.
The loading door opens on its own. The loading door might not be closed properly. Push the loading door until you hear the closing sound.
The water tank warning symbol is on/flashing. The water tank might be full. Empty the water tank.
The water discharge hose might be bent. If the product is connected directly to the water outlet, check the water discharge hose.
The heat exchanger cleaning warning symbol is on. The heat exchanger might be unclean. Clean the heat exchanger.
The filter cleaning warning symbol is on. The lint filter might be unclean. Clean the filter.
The filter seat might be clogged by lint. Clean the filter seat.
The filter and heat exchanger cleaning warning symbol are flashing. There might be a layer that causes obstruction on the surface of the lint filter. Wash the filter with lukewarm water.
The filter seat might be clogged by lint. Clean the filter seat.
There might be a layer that causes obstruction on the surface of the lint filter. Wash the filter with lukewarm water.
The heat exchanger might be clogged. Clean the heat exchanger.
The program can not be started and the filter warning led is blinking. The filter may not be placed. Replace the filter.
The filter warning led is blinking even though the filter is placed. Call technical service.
